HP HPE6-A73 Practice Test - Questions Answers, Page 3

Add to Whishlist

List of questions

Question 21

Report Export Collapse

A company has an existing wireless solution involving Aruba APs and Mobility controllers running 8.4 code.

The solution leverages a third-party AAA solution. The company is replacing existing access switches with AOS-CX 6300 and 6400 switches. The company wants to leverage the same security and firewall policies for both wired and wireless traffic.

Which solution should the company implement?

RADIUS dynamic authorization
RADIUS dynamic authorization
Downloadable user roles
Downloadable user roles
IPSec
IPSec
User-based tunneling
User-based tunneling
Suggested answer: D
asked 16/09/2024
Tomasz Woloszczak
46 questions

Question 22

Report Export Collapse

A network engineer is having a problem adding a custom-written script to an AOS-CX switch's NAE GUI. The script was written in Python and was successfully added on other AOS-CX switches. The engineer examines the following items from the CLI of the switch:

HP HPE6-A73 image Question 22 14591 09162024180711000000

What should the engineer perform to fix this issue?

Install the script's signature before installing the new script
Install the script's signature before installing the new script
Ensure the engineer's desktop and the AOS-CX switch are synchronized to the same NTP server
Ensure the engineer's desktop and the AOS-CX switch are synchronized to the same NTP server
Enable trust settings for the AOS-CX switch's SSL certificate
Enable trust settings for the AOS-CX switch's SSL certificate
Remove a script that is no longer used before installing the new script
Remove a script that is no longer used before installing the new script
Suggested answer: D
asked 16/09/2024
Joshin Ogele
40 questions

Question 23

Report Export Collapse

Which option correctly defines how to identify a VLAN as a voice VLAN on an AOS-CX switch?

Switch(config)# port-access lldp-group <LLDP-group-name>Switch(config-lldp-group)# vlan <VLAN-ID>
Switch(config)# port-access lldp-group <LLDP-group-name>Switch(config-lldp-group)# vlan <VLAN-ID>
Switch(config)# port-access role <role-name>Switch(config-pa-role)# vlan access <VLAN-ID>
Switch(config)# port-access role <role-name>Switch(config-pa-role)# vlan access <VLAN-ID>
Switch(config)# vlan <VLAN-ID>Switch(config-vlan-<VLAN-ID>)# voice
Switch(config)# vlan <VLAN-ID>Switch(config-vlan-<VLAN-ID>)# voice
Switch(config)# vlan <VLAN-ID> voice
Switch(config)# vlan <VLAN-ID> voice
Suggested answer: C
asked 16/09/2024
Chet Camlin
40 questions

Question 24

Report Export Collapse

An administrator will be replacing a campus switching infrastructure with AOS-CX switches that support VSX capabilities. The campus involves a core, as well as multiple access layers. Which feature should the administrator implement to allow both VSX-capable core switches to process traffic sent to the default gateway in the campus VLANs?

VRF
VRF
VRRP
VRRP
IP helper
IP helper
Active gateway
Active gateway
Suggested answer: D
Explanation:

Active gateway = both devices route/forward traffic VRRP = Active-standbye, only active member routes/forwards traffic Understand the Active Gateway principle In a VSX system, active gateway provides redundant default gateway functionality for the end-hosts. The default gateway of the end-host is automatically handled by both the VSX systems.

asked 16/09/2024
Piotr Jakubowski
44 questions

Question 25

Report Export Collapse

What is correct regarding the tunneling of user traffic between AOS-CX switches and Aruba Mobility Controllers (MCs)?

Uses IPSec to protect the management and data traffic
Uses IPSec to protect the management and data traffic
Uses IPSec to protect the management traffic
Uses IPSec to protect the management traffic
Supports only port-based tunneling
Supports only port-based tunneling
Uses the same management protocol as Aruba APs
Uses the same management protocol as Aruba APs
Suggested answer: D
asked 16/09/2024
Arturs Grigorjevs
48 questions

Question 26

Report Export Collapse

An administrator is implementing a multicast solution in a multi-VLAN network. Which statement is true about the configuration of the switches in the network?

IGMP snooping must be enabled on all interfaces on a switch to intelligently forward traffic
IGMP snooping must be enabled on all interfaces on a switch to intelligently forward traffic
IGMP requires join and leave messages to graft and prune multicast streams between switches
IGMP requires join and leave messages to graft and prune multicast streams between switches
IGMP must be enabled on all routed interfaces where multicast traffic will traverse
IGMP must be enabled on all routed interfaces where multicast traffic will traverse
IGMP must be enabled on all interfaces where multicast sources and receivers are connected
IGMP must be enabled on all interfaces where multicast sources and receivers are connected
Suggested answer: C
asked 16/09/2024
Philippe Chretien
46 questions

Question 27

Report Export Collapse

How is voice traffic prioritized correctly on AOS-CX switches?

By defining device profiles with QOS settings
By defining device profiles with QOS settings
By placing it in the strict priority queue
By placing it in the strict priority queue
By implementing voice VLANs
By implementing voice VLANs
By implementing weighted fair queueing (WFQ)
By implementing weighted fair queueing (WFQ)
Suggested answer: B
asked 16/09/2024
Sathiyaraj Arulprakasam
53 questions

Question 28

Report Export Collapse

An administrator is replacing the current access switches with AOS-CX switches. The access layer switches must authenticate user and networking devices connecting to them. Some devices support no form of authentication, and some support 802.1X. Some ports have a VoIP phone and a PC connected to the same port, where the PC is connected to the data port of the phone and the phone's LAN port is connected to the switch.

Which statement is correct about this situation?

802.1X must be configured to work in fallback mode
802.1X must be configured to work in fallback mode
Device fingerprinting is required for authentication
Device fingerprinting is required for authentication
The client-limit setting for port access needs to be changed
The client-limit setting for port access needs to be changed
Device mode should be implemented
Device mode should be implemented
Suggested answer: C
asked 16/09/2024
Nogueira Elder
44 questions

Question 29

Report Export Collapse

A network engineer for a company with 896 users across a multi-building campus wants to gather statistics on an important switch uplink and create actions based on issues that occur on the uplink.

How often does an NAE agent gather information from the current state database in regard to the uplink interfaces?

Once every 60 seconds
Once every 60 seconds
Once every 1 second
Once every 1 second
Once every 30 seconds
Once every 30 seconds
Once every 5 seconds
Once every 5 seconds
Suggested answer: D
asked 16/09/2024
AHMED MAHMOUD NASR Hassan
38 questions

Question 30

Report Export Collapse

How does PIM build the IP multicast routing table to route traffic between a multicast source and one or more receivers?

It uses the unicast routing table and reverse path forwarding (RPF)
It uses the unicast routing table and reverse path forwarding (RPF)
It uses IGMP and calculates a shortest path tree (SPT)
It uses IGMP and calculates a shortest path tree (SPT)
It uses the shortest path first (SPF) algorithm derived from link state protocols
It uses the shortest path first (SPF) algorithm derived from link state protocols
It uses the Bellman-Ford algorithm derived from distance vector protocols
It uses the Bellman-Ford algorithm derived from distance vector protocols
Suggested answer: A
Explanation:

"PIM also relies on the unicast routing tables to identify the path back to a multicast source. This routing method is known as reverse path forwarding (RPF). The unicast routing protocols create the unicast routing tables. With this information, PIM sets up the distribution tree for the multicast traffic.

asked 16/09/2024
Wasawatt Ch
42 questions
Total 127 questions
