VMware 2V0-41.20 Practice Test - Questions Answers, Page 3

List of questions

Question 21

Report Export Collapse

An NSX administrator is using ping to check connectivity between VM1 running on ESXi1 to VM2 running on ESXi2. The ping tests fails. The administrator knows the maximum transmission unit size on the physical switch is 1600.

Which command does the administrator use to check the VMware kernel ports for tunnel end point communication?

esxcli network diag ping -H <destination IP address>
esxcli network diag ping -H <destination IP address>
vmkping ++netstack=geneve -d -s 1572 <destination IP address>
vmkping ++netstack=geneve -d -s 1572 <destination IP address>
vmkping ++netstack=vxlan-d -s 1572 <destination IP address>
vmkping ++netstack=vxlan-d -s 1572 <destination IP address>
esxcli network diag ping -I vmk0 -H <destination IP address>
esxcli network diag ping -I vmk0 -H <destination IP address>
Suggested answer: C
Explanation:

https://kb.vmware.com/s/article/1003728

asked 16/09/2024
Antonio Carlos Figueiredo Junior
55 questions

Question 22

Report Export Collapse

How is the RouterLink port created between a Tier-1 Gateway and Tier-0 Gateway?

Automatically created when Tier-1 is created.
Automatically created when Tier-1 is created.
Manually create a Segment and connect to both Tier-1 and Tier-0 Gateways.
Manually create a Segment and connect to both Tier-1 and Tier-0 Gateways.
Manually create a Logical Switch and connect to bother Tier-1 and Tier-0 Gateways.
Manually create a Logical Switch and connect to bother Tier-1 and Tier-0 Gateways.
Automatically created when Tier-1 is connected with Tier-0 from NSX UI.
Automatically created when Tier-1 is connected with Tier-0 from NSX UI.
Suggested answer: D
Explanation:

Reference:

https://docs.vmware.com/en/VMware-NSX-T-Data-Center/3.0/administration/GUID-3F163DEE-1EE6-4D80-BEBF-8D109FDB577C.html

asked 16/09/2024
Anthony Wilson
44 questions

Question 23

Report Export Collapse

What is the most restrictive NSX-T built-in role which will allow a user to apply configuration changes on a NSX Edge?

Cloud Service Administrator
Cloud Service Administrator
Network Engineer
Network Engineer
Network Operator
Network Operator
NSX Administrator
NSX Administrator
Suggested answer: B
asked 16/09/2024
Glenn Abdoelkarim
39 questions

Question 24

Report Export Collapse

A customer is preparing to deploy VMware Kubernetes on an NSX-T Data Center.

What is the minimum MTU size for the UPLINK profile?

1500
1500
1650
1650
1550
1550
1600
1600
Suggested answer: D
asked 16/09/2024
Brooke Galiata
34 questions

Question 25

Report Export Collapse

Which tool could be used to inspect the path of a packet in the data plane?

Port Connection
Port Connection
Port Mirroring Session
Port Mirroring Session
Netflow
Netflow
Traceflow
Traceflow
Suggested answer: D
asked 16/09/2024
ERIC MERRILL
46 questions

Question 26

Report Export Collapse

Which two statements are true about the implementation of multicast in NSX-T Data Center?

(Choose two.)

Multicast routing is implemented with PIM Sparse-Mode.
Multicast routing is implemented with PIM Sparse-Mode.
IGMP Snooping is used to populate multicast forwarding tables.
IGMP Snooping is used to populate multicast forwarding tables.
Tier-0 gateways can be the Rendezvous Point.
Tier-0 gateways can be the Rendezvous Point.
Multicast is supported in ESXi and KVM transport nodes.
Multicast is supported in ESXi and KVM transport nodes.
An Edge can be the Rendezvous Point.
An Edge can be the Rendezvous Point.
Suggested answer: A, B
Explanation:


https://docs.vmware.com/en/VMware-NSX-T-Data-Center/3.0/nsxt_30_admin.pdf

asked 16/09/2024
Rico Banagale
44 questions

Question 27

Report Export Collapse

An NSX administrator has deployed an NSX Edge on a bare-metal server.

Which command registers the NSX Edge with the NSX Manager?

join management-cluster <nsx-cluster-IP> username admin password <adminpassword> thumbprint <nsx-manager-thumbprint>
join management-cluster <nsx-cluster-IP> username admin password <adminpassword> thumbprint <nsx-manager-thumbprint>
join cluster <nsx-cluster-IP> username root password <root-password> thumbprint <nsx-manager—thumbprint>
join cluster <nsx-cluster-IP> username root password <root-password> thumbprint <nsx-manager—thumbprint>
join policy-manager <nsx-manager-ip> username root password <root-password> thumbprint <nsx-manager-thumbprint>
join policy-manager <nsx-manager-ip> username root password <root-password> thumbprint <nsx-manager-thumbprint>
join management-plane <nsx-nanager-ip> username admin password <admin-password> thumbprint <nsx-manager-thumbprint>
join management-plane <nsx-nanager-ip> username admin password <admin-password> thumbprint <nsx-manager-thumbprint>
Suggested answer: D
asked 16/09/2024
Meena Utsaha
34 questions

Question 28

Report Export Collapse

Refer to the exhibit.

VMware 2V0-41.20 image Question 28 9229 09162024012453000000

Which NAT type must the NSX-T Data Center administrator create on the Tier-0 or Tier-1 Gateway to allow Web VM to initiate communication with public networks?

SNAT
SNAT
Reverse NAT
Reverse NAT
DNAT
DNAT
1:1 NAT
1:1 NAT
Suggested answer: A
asked 16/09/2024
Débora Gomes Almeida
49 questions

Question 29

Report Export Collapse

How does the Traceflow tool identify issues in a network?

Compares intended network state in the control plane with Tunnel End Point (TEP) keepalives in the data plane.
Compares intended network state in the control plane with Tunnel End Point (TEP) keepalives in the data plane.
Compares the management plane configuration states containing control plane traffic and error reporting from transport node agents.
Compares the management plane configuration states containing control plane traffic and error reporting from transport node agents.
Injects synthetic traffic into the data plane and observes the results in the control plane.
Injects synthetic traffic into the data plane and observes the results in the control plane.
Injects ICMP traffic into the data plane and observes the results in the control plane.
Injects ICMP traffic into the data plane and observes the results in the control plane.
Suggested answer: C
asked 16/09/2024
Tim baxter
48 questions

Question 30

Report Export Collapse

Which statement is true about an alarm in a Suppressed state?

An alarm can be suppressed for a specific duration in days.
An alarm can be suppressed for a specific duration in days.
An alarm can be suppressed for a specific duration in minutes.
An alarm can be suppressed for a specific duration in minutes.
An alarm can be suppressed for a specific duration in seconds.
An alarm can be suppressed for a specific duration in seconds.
An alarm can be suppressed for a specific duration in hours.
An alarm can be suppressed for a specific duration in hours.
Suggested answer: D
Explanation:

Reference:

https://docs.vmware.com/en/VMware-NSX-Intelligence/1.1/user-guide/GUID-EBD3C5A8-F9AB-4A22-BA40-92D61850C1E6.html"If you move an alarm into a Suppressed state, you are prompted to specify the duration in hours.

After the specified duration passes, the alarm state reverts to Open. However, if the system determines the condition has been corrected, the alarm state changes to Resolved."

https://docs.vmware.com/en/VMware-NSX-T-Data-Center/3.0/administration/GUID-EB1BB1D3-8892-4890-BE74-EF43CFC75F19.html

asked 16/09/2024
Nghia To Duc
58 questions
Total 93 questions
