Box 1: 4

Two public IP addresses in the on-premises data center, and two public IP addresses in the VNET.

The most reliable option is to combine the active-active gateways on both your network and Azure, as shown in the diagram below.

Box 2: 2

Every Azure VPN gateway consists of two instances in an active-standby configuration. For any planned maintenance or unplanned disruption that happens to the active instance, the standby instance would take over (failover) automatically, and resume the S2S VPN or VNet-to-VNet connections.

Box 3: 2

Dual-redundancy: active-active VPN gateways for both Azure and on-premises networks

Reference:

https://docs.microsoft.com/en-us/azure/vpn-gateway/vpn-gateway-highlyavailable

Reference:

https://docs.microsoft.com/en-us/azure/vpn-gateway/vpn-gateway-about-point-to-site-routing

You can move an app to another App Service plan, as long as the source plan and the target plan are in the same resource group and geographical region.

The region in which your app runs is the region of the App Service plan it's in. However, you cannot change an App Service plan's region.

Reference: https://docs.microsoft.com/en-us/azure/app-service/app-service-plan-manage

You apply tags to your Azure resources, resource groups, and subscriptions to logically organize them into a taxonomy. Each tag consists of a name and a value pair. For example, you can apply the name "Environment" and the value "Production" to all the resources in production

Reference:

https://docs.microsoft.com/en-us/azure/billing/billing-getting-started

https://docs.microsoft.com/en-us/azure/azure-resource-manager/resource-group-using-tags

Through activity logs, you can determine:

ß what operations were taken on the resources in your subscription

ß who started the operation

ß when the operation occurred

ß the status of the operation

ß the values of other properties that might help you research the operation

1. On the Azure portal menu, select Monitor, or search for and select Monitor from any page

2. Select Activity Log.

3. You see a summary of recent operations. A default set of filters is applied to the operations. Notice the information on the summary includes who started the action and when it happened.

Reference:

https://docs.microsoft.com/en-us/azure/azure-resource-manager/management/view-activity-logs

Box 1: "/subscription/c276fc76-9cd4-44c9-99a7-4fd71546436e"

In the assignableScopes you need to mention the subscription ID where you want to implement the RBAC

Box 2: "Microsoft.Authorization/*"

Microsoft.Authorization/* is used to Manage authorization

Reference:

https://docs.microsoft.com/en-us/azure/role-based-access-control/resource-provideroperations#microsoftauthorization

https://docs.microsoft.com/en-us/azure/role-based-access-control/built-in-roles

Reference:

https://docs.microsoft.com/en-us/azure/role-based-access-control/custom-roles

https://docs.microsoft.com/en-us/azure/role-based-access-control/resource-provideroperations#microsoftresources

Box 1: Cloud-init.txt

Cloud-init.txt is used to customize a Linux VM on first boot up. It can be used to install packages and write files, or to configure users and security. No additional steps or agents are required to apply your configuration.

Box 2: The az vm create command

Once Cloud-init.txt has been created, you can deploy the VM with az vm create cmdlet, sing the --customdata parameter to provide the full path to the cloud-init.txt file.

Reference:

https://docs.microsoft.com/en-us/azure/virtual-machines/linux/tutorial-automate-vm-deployment

Box 1: Assign a tag to each resource.

You apply tags to your Azure resources giving metadata to logically organize them into a taxonomy.

After you apply tags, you can retrieve all the resources in your subscription with that tag name and value. Each resource or resource group can have a maximum of 15 tag name/value pairs. Tags applied to the resource group are not inherited by the resources in that resource group.

Box 2: From the Cost analysis blade, filter the view by tag

After you get your services running, regularly check how much they're costing you. You can see the current spend and burn rate in Azure portal.

Visit the Subscriptions blade in Azure portal and select a subscription.

You should see the cost breakdown and burn rate in the popup blade.

Click Cost analysis in the list to the left to see the cost breakdown by resource. Wait 24 hours after you add a service for the data to populate.

You can filter by different properties like tags, resource group, and timespan. Click Apply to confirm the filters and Download if you want to export the view to a Comma-Separated Values (.csv) file.

Box 3: Download the usage report

Reference:

https://docs.microsoft.com/en-us/azure/azure-resource-manager/resource-group-using-tags

https://docs.microsoft.com/en-us/azure/billing/billing-getting-started
