MuleSoft MCIA - Level 1 Practice Test - Questions Answers, Page 6
List of questions
Related questions
Question 51
![Export Export](https://examgecko.com/assets/images/icon-download-24.png)
An organization's governance process requires project teams to get formal approval from all key stakeholders for all new Integration design specifications. An integration Mule application Is being designed that interacts with various backend systems. The Mule application will be created using Anypoint Design Center or Anypoint Studio and will then be deployed to a customer-hosted runtime.
What key elements should be included in the integration design specification when requesting approval for this Mule application?
Explanation:
SLAs and non-functional requirements to access the backend systems. Only this option actually speaks to design parameters and reqs. * Below two are technical implementations and not the part of design: - Snapshots of the Mule application's flows, including their error handling - The credentials to access the backend systems and contact details for the administrator of each system * List of consumers is not relevant to the design
Question 52
![Export Export](https://examgecko.com/assets/images/icon-download-24.png)
A set of integration Mule applications, some of which expose APIs, are being created to enable a new business process. Various stakeholders may be impacted by this. These stakeholders are a combination of semi-technical users (who understand basic integration terminology and concepts such as JSON and XML) and technically skilled potential consumers of the Mule applications and APIs.
What Is an effective way for the project team responsible for the Mule applications and APIs being built to communicate with these stakeholders using Anypoint Platform and its supplied toolset?
Explanation:
As the stakeholders are semitechnical users , preferred option is Create Anypoint Exchange entries with pages elaborating the integration design, including API notebooks (where applicable) to help the stakeholders understand and interact with the Mule applications and APIs at various levels of technical depth
Question 53
![Export Export](https://examgecko.com/assets/images/icon-download-24.png)
An integration Mute application consumes and processes a list of rows from a CSV file. Each row must be read from the CSV file, validated, and the row data sent to a JMS queue, in the exact order as in the CSV file.
If any processing step for a row falls, then a log entry must be written for that row, but processing of other rows must not be affected.
What combination of Mute components is most idiomatic (used according to their intended purpose) when Implementing the above requirements?
Explanation:
* On Error Propagate halts execution and sends error to the client. In this scenario it's mentioned that "processing of other rows must not be affected" so Option B and C are ruled out.
* Scatter gather is used to club multiple responses together before processing. In this scenario, we need sequential processing. So option A is out of choice.
* Correct answer is For Each scope & On Error Continue scope Below requirement can be fulfilled in the below way
1) Using For Each scope , which will send each row from csv file sequentially. each row needs to be sent sequentially as requirement is to send the message in exactly the same way as it is mentioned in the csv file
2) Also other part of requirement is if any processing step for a row fails then it should log an error but should not affect other record processing . This can be achieved using On error Continue scope on these set of activities. so that error will not halt the processing. Also logger needs to be added in error handling section so that it can be logged.
* Attaching diagram for reference. Here it's try scope, but similar would be the case with For Each loop.
Question 54
![Export Export](https://examgecko.com/assets/images/icon-download-24.png)
An organization's security policies mandate complete control of the login credentials used to log in to Anypoint Platform. What feature of Anypoint Platform should be used to meet this requirement?
Explanation:
Correct answer is Federated Identity Management As the Anypoint Platform organization administrator, you can configure identity management in Anypoint Platform to set up users for single sign-on (SSO). Configure identity management using one of the following single sign-on standards:
OpenID Connect: End user identity verification by an authorization server including SSO SAML 2.0:
Web-based authorization including cross-domain SSO Where as Client Management is where Anypoint Platform acts as a client provider by default, but you can also configure external client providers to authorize client applications. As an API owner, you can apply an OAuth 2.0 policy to authorize client applications that try to access your API. You need an OAuth 2.0 provider to use an OAuth 2.0 policy
Reference: https://help.mulesoft.com/s/article/How-federated-users-are-mapped-to-Anypoint-Platform-Business-Groups-when-External-Identity-is-enabled
https://docs.mulesoft.com/access-management/external-identity
Question 55
![Export Export](https://examgecko.com/assets/images/icon-download-24.png)
Refer to the exhibit.
An organization is sizing an Anypoint VPC for the non-production deployments of those Mule applications that connect to the organization's on-premises systems. This applies to approx. 60 Mule applications. Each application is deployed to two CloudHub i workers. The organization currently has three non-production environments (DEV, SIT and UAT) that share this VPC. The AWS region of the VPC has two AZs.
The organization has a very mature DevOps approach which automatically progresses each application through all non-production environments before automatically deploying to production.
This process results in several Mule application deployments per hour, using CloudHub's normal zero-downtime deployment feature.
What is a CIDR block for this VPC that results in the smallest usable private IP address range?
Explanation:
Mule applications are deployed in CloudHub workers and each worker is assigned with a dedicated IP
ï For zero downtime deployment, each worker in CloudHub needs additional IP addresses
ï A few IPs in a VPC are reserved for infrastructure (generally 2 IPs)
ï The IP addresses are usually in a private range with a subnet block specifier, such as 10.0.0.1/24
ï The smallest CIDR network subnet block you can assign for your VPC is /24 (256 IP addresses) (60*3 env * 2 worker per application ) + 50% of (total) for zero downtime = 540 In this case correct answer is 10.0.0.0/22 as this provided 1024 IP's .
Other IP's are insufficient.
Question 56
![Export Export](https://examgecko.com/assets/images/icon-download-24.png)
What Is a recommended practice when designing an integration Mule 4 application that reads a large XML payload as a stream?
Explanation:
If the size of the stream exceeds the maximum, a STREAM_MAXIMUM_SIZE_EXCEEDED error is raised.
Question 57
![Export Export](https://examgecko.com/assets/images/icon-download-24.png)
Anypoint Exchange is required to maintain the source code of some of the assets committed to it, such as Connectors, Templates, and API specifications.
What is the best way to use an organization's source-code management (SCM) system in this context?
Explanation:
* Organization should continue to use SCM system of their choice, in addition to keeping source code for these asset types in Anypoint Exchange, thereby enabling parallel development, branching.
* Reason is that Anypoint exchange is not full fledged version repositories like GitHub.
* But at same time it is tightly coupled with Mule assets
Question 58
![Export Export](https://examgecko.com/assets/images/icon-download-24.png)
What Anypoint Connectors support transactions?
Explanation:
Below Anypoint Connectors support transactions ? JMS ñ Publish ñ Consume ? VM ñ Publish ñ Consume ? Database ñ All operations
Question 59
![Export Export](https://examgecko.com/assets/images/icon-download-24.png)
A Mule application is deployed to a cluster of two(2) cusomter-hosted Mule runtimes. Currently the node name Alice is the primary node and node named bob is the secondary node. The mule application has a flow that polls a directory on a file system for new files.
The primary node Alice fails for an hour and then restarted.
After the Alice node completely restarts, from what node are the files polled, and what node is now the primary node for the cluster?
Explanation:
* Mule High Availability Clustering provides basic failover capability for Mule. * When the primary Mule Runtime becomes unavailable, for example, because of a fatal JVM or hardware failure or it's taken offline for maintenance, a backup Mule Runtime immediately becomes the primary node and resumes processing where the failed instance left off. * After a system administrator recovers a failed Mule Runtime server and puts it back online, that server automatically becomes the backup node. In this case, Alice, once up, will become backup -------------------------------------------------------------------------- -------------------------------------------------------------------- Reference: https://docs.mulesoft.com/muleruntime/ 4.3/hadr-guide So correct choice is : Files are polled form Bob node Bob is now the primary node
Question 60
![Export Export](https://examgecko.com/assets/images/icon-download-24.png)
An Organization has previously provisioned its own AWS VPC hosting various servers. The organization now needs to use Cloudhub to host a Mule application that will implement a REST API once deployed to Cloudhub, this Mule application must be able to communicate securely with the customer-provisioned AWS VPC resources within the same region, without being interceptable on the public internet.
What Anypoint Platform features should be used to meet these network communication requirements between Cloudhub and the existing customer-provisioned AWS VPC?
Explanation:
Correct answer is: Add a Mulesoft hosted Anypoint VPC configured and with VPC Peering to the AWS VPC
* Connecting to your Anypoint VPC extends your corporate network and allows CloudHub workers to access resources behind your corporate firewall.
* You can connect on-premises data centers through a secured VPN tunnel, or a private AWS VPC through VPC peering, or by using AWS Direct Connect.
MuleSoft Doc Reference : https://docs.mulesoft.com/runtime-manager/virtual-private-cloud
