Tableau TDS-C01 Practice Test - Questions Answers, Page 30

Bar charts in Tableau do not require a dimension to be created. You can create a bar chart using only a measure; this will produce a single bar that represents the aggregate of the measure values, such as the sum or average of sales.

In Tableau, to create a reference line, one of the axes in the view must contain an aggregated measure. Reference lines are typically used to add context or additional information to the data in a view, and they are often based on some form of aggregate such as the average, median, sum, etc., of a measure.

To invert the color intensity of a quantitative range in Tableau, you should use the 'Reversed' option. This option inverts the color scheme so that the colors representing the higher values are swapped with those representing the lower values. For example, if a color scale initially shows dark colors for high values and light colors for low values, using 'Reversed' will switch this so that dark colors represent low values and light colors represent high values. This option is particularly useful for better visual distinction and interpretation in certain data scenarios.

Dashboard actions in Tableau are interactive elements that can be used to create a more dynamic experience. These actions can be set to filter data on the dashboard, highlight specific elements, or even direct the user to a URL when interacting with a visualization. They can be triggered by user interaction such as hover, selection, or accessing a context menu. Moreover, dashboard actions can have multiple source sheets (where the action originates) and target sheets (where the action takes effect), allowing for a complex interactivity between different parts of the dashboard.

In Tableau, you can rename a field directly in the Data pane by clicking and holding on the field name until it becomes editable, allowing you to type a new name. Alternatively, you can use the drop-down menu associated with the field in the Data pane and select the 'Rename' option. Both methods provide a quick and easy way to change the name of a field without affecting the underlying data structure. The 'Format menu' and 'Replace Reference' option do not apply to renaming fields.

For a scatter plot view in Tableau, you can add reference lines and trend lines as part of the analytics options. Reference lines can be added to a visualization to mark certain values or to provide context, such as an average line across a scatter plot. Trend lines, on the other hand, are used to show the relationship between two variables in the view, indicating the general direction or pattern of the data points in a scatter plot.

When exporting a view as an image in Tableau, the default export includes everything that is currently displayed in the view, with Tableau applying its own styling, including fonts. The default format for an exported image is PNG, which is a raster-based file format that captures all visual elements as pixels. PNG is widely used for its lossless compression and is suitable for detailed images like those produced by Tableau. Unlike vector-based images, PNGs do not embed fonts, and the image quality remains consistent when the image is viewed on different platforms, which makes it ideal for inserting into documents like Microsoft Word.

In Tableau, a Density map (also known as a heat map) uses automatically generated sizes for the data points that cannot be resized by using the Marks card. This chart type is designed to display density of data points on a map, where the size and color of the data points represent the concentration of data in that area.

To set the default properties of a field to Currency in Tableau, you need to configure the number format of the field from the Data pane. This can be done by right-clicking the field in the Data pane and selecting Default Properties, then choosing the appropriate number format (in this case, Currency).
