Which two types of NAT are used in a network? (Choose two.)
routed NAT
static NAT
multicast NAT
normal NAT
dynamic NAT
What is the purpose of a MAC address?
to uniquely identify a switch in a LAN
to uniquely identify a router in a LAN
to uniquely identify a network interface in a LAN
to uniquely identify a device on the Internet
Refer to the exhibit.
Which two statements about the network diagram are true? (Choose two.)
The subnet address of PC-B has 18 bits dedicated to the network portion.
One of the routers has two connected serial interfaces.
R1 and R3 are in the same subnet.
PC-A and PC-B are in the same subnet.
The subnet of PC-C can contain 256 hosts.
Which detail is included in a routing table?
broadcast address
TCP or UDP port number
IP protocol
destination next hop or outgoing interface
What is an example of a network interface hardware address?
workstation name
IP address
domain name
MAC address
On which network plane is routing protocol traffic handled?
management plane
data plane
authentication plane
control plane
Which device is used to transport traffic from one broadcast domain to another broadcast domain?
layer 2 switch
proxy server
router
load balancer
Which service provides a directory lookup for IP addresses and host names?
DNS
NAT
SNMP
DHCP
Users cannot access a webserver and after the traffic is captured, the capture tool shows an ICMP packet that reports "time exceeded in-transit". What is the cause of this webserver access issue?
A router along the path has the wrong time.
A router along the path is misrouting the packets in a wrong direction.
The server is too loaded and the connection could not be handled in time.
The server is too far away and the packets require too much time to reach it.
What is used in Layer 2 switches to direct packet transmission to the intended recipient?
MAC address
IPv6 address
spanning tree
IPv4 address
