A network administrator is configuring a tunnel interface on a branch Cisco IOS XE router to run TLOC extensions. Which configuration will extend a TLOC over a GRE tunnel to another router in the branch?
Option A
Option B
Option C
Option D
Which two products that perform lifecycle management for virtual instances are supported by WAN Edge cloud routers? (Choose two.)
OpenStack
AWS
VMware vCenter
Azure
IBM Cloud
A network administrator is creating an OMP feature template from the vManage GUI to be applied to WAN edge routers. Which configuration attribute will avoid the redistribution of the routes back into the OMP from the LAN side?
configure "Number of Paths Advertised per Prefix"
configure "Overlay AS Number"
configure "Send Backup Paths"
configure "ECMP limit"
If Smart Account Sync is not used, which Cisco SD-WAN component is used to upload an authorized serial number file?
WAN Edge
vManage
vSmart
vBond
An engineer is tasked to improve throughput for connection-oriented traffic by decreasing round-trip latency. Which configuration will achieve this goal?
turn on "Enable TCP Optimization"
turn off "Enhance ECMP Keying"
turn off "Enable TCP Optimization"
turn on "Enhance ECMP Keying"
Which secure connection should be used to access the REST APIs through the Cisco vManage web server?
HTTP inspector interface
authenticated HTTPS
authenticated DTLS
JSON Inspector interface
Refer to the exhibit.
A network administrator is configuring OMP in vManage to advertise all the paths for the same prefix from a site that has two WAN Edge devices Each WAN Edge device is connected to three ISPs and two private MPLS transports. What is the minimum value for 'Number of Paths advertised per Prefix" that should be configured?
2
3
5
10
Refer to the exhibit.
An engineer is troubleshooting an issue where vManage and vSmart have a problem establishing a connection to vBond. Which action fixes the issue?
Reconfigure the vBond command on the vBond as vBond 150.5.1.3 local
Configure the tunnel interface on all three controllers with a color of transport
Remove the encapsulation IPsec command under the tunnel interface of vBond.
Configure encapsulation as IPsec under the tunnel interface of vManage and vSmart
Refer to the exhibit.
An engineer is configuring service chaining. Which set of configurations is required for all traffic from Site ID 1 going toward Site ID 2 to get filtered through the firewall on the hub site?
In a Cisco SD-WAN architecture, what is the role of the WAN Edge?
It provides orchestration to assist in automatic provisioning of WAN Edge routers and overlay
It is the management plane responsible for centralized configuration and monitoring
It is the control plane that builds and maintains network topology
It is the data plane that is responsible for forwarding traffic
