Question 191

(0)

Which two overlay network design considerations must be made for a Cisco SD-Access network? (Choose two.)

Question 192

(0)

Refer to the exhibit. An architect is designing a routing solution for a company. The new design will add a circuit routers C and D to protect against loss of connectivity to 10.0.4.0/24 during a

Question 193

(0)

Which two functions is the Cisco SD-Access Edge Node responsible for? (Choose two.)

Question 194

(0)

A company needs to increase access port capacity on one floor of a building. They want to leverage the existing catalyst access switch. There is no problem with uplink bandwidth capacity. However, n

Question 195

(0)

Which queuing structure is used on SD-WAN Edge routers?

Question 196

(0)

Since installing a cisco TelePresence system, the company is experiencing other application having response issues when the system in use. As a result, the company asked an architect to recommend a

Question 197

(0)

A company plans to transition to IPv6. They will link their IPv4 addresses to the lowest significant bits of the new Ipv6 addresses. A network administrator with an employee id: 4264:42:116 is prepa

Question 198

(0)

DRAG DROP Drag and drop the characteristics from the left onto the YANG models they describe on the right. Not all options are used.

Question 199

(0)

DRAG DROP Drag and drop the elements from the left onto the protocols where they are used on the right.

Question 200

(0)

DRAG DROP Drag and drop the model-driven telemetry considerations from the left onto the modes they apply to on the right.

Related questions

Which queuing structure is used on SD-WAN Edge routers?

DRAG DROP Drag and drop the characteristics from the left onto the correct telemetry mode on the right.

Which consideration must be taken into account when using the DHCP relay feature in a Cisco SDAccess Architecture?

Which WAN connectivity technology is optimal for edge computing compared to others and why?

Which feature is used to optimize WAN bandwidth of IGMP network traffic among WAN Edge routers in the same VPN?

An engineer must design an in-band management solution for a customer with branch sites. The solution must allow remote management of the branch sites using management protocols over an MPLS WAN. Queueing is implemented at the remote sites using these classes: How must the solution prioritize the management traffic over the WAN?

An architect must create a QoS solution for a customer to ensure that a 40 Mbps Internet connection is shared between four subnets based on these requirements: * Each subnet must receive no less than 10 Mbps of download bandwidth during peak traffic times. * A subnet can use up to 40 Mbps during nonpeak traffic times if the other subnets are idle. * Download traffic must never experience a delay. Which solution must the architect choose?

An engineer must design a QoS solution for a customer. The network currently supports data only, but the customer will roll out VoIP and IP video in conjunction with the new QoS solution. The engineer plans to use DiffServ. To ensure priority for voice services, which model must the design include?

Which two functions does the control plane node provide in a Cisco SD-Access architecture? (Choose two.)

Refer to the exhibit. An engineer must design a WAN solution so that ISP-1 is always preferred over ISP-2. The path via ISP-2 is considered as a backup and must be used only when the path to ISP-1 is down. Which solution must the engineer choose? A. R1: - Routes advertised to ISP-1: 0x AS-path prepend - Routes received from ISP-1: HIGH local-preference - Routes advertised to R2: no action - Routes received from R2: community NO-EXPORT R2: - Routes advertised to ISP-2:5x AS-path prepend - Routes received from ISP-2: LOW local-preference - Routes advertised to R1: community NO-ADVERTISE - Routes received from R1: no action

Question 191

Which two overlay network design considerations must be made for a Cisco SD-Access network?

(Choose two.)

LAN automation for deployment

Layer 3 to the access design

Reduce subnets and simplify DHCP management

Dedicated IGP process for the fabric

Avoid overlapping IP subnets

Show Answer Comment (0)

An architect is designing a routing solution for a company. The new design will add a circuit routers C and D to protect against loss of connectivity to 10.0.4.0/24 during a link failure between routers B and D. Which solution must the architect choose?

Stub connected

Stub redistributed

Stub receive-only

Stub leak-map

Show Answer Comment (0)

Question 193

Which two functions is the Cisco SD-Access Edge Node responsible for? (Choose two.)

Act as anycast layer 3 gateway

Advertise EID subnets

Map users to virtual network

Act as LISP proxy tunnel router

Route and transport IP traffic

Show Answer Comment (0)

Question 194

A company needs to increase access port capacity on one floor of a building. They want to leverage the existing catalyst access switch. There is no problem with uplink bandwidth capacity. However, no additional uplinks can be added because no ports are available on the distribution switches. Which solution must the company choose to provide additional access ports?

VDC

VSS

Etherchannel

Stackwise

Show Answer Comment (0)

Question 195

Which queuing structure is used on SD-WAN Edge routers?

FIFO

LLQ+WFQ

1P-4Q-2T

Priority

Show Answer Comment (0)

Question 196

Since installing a cisco TelePresence system, the company is experiencing other application having response issues when the system in use. As a result, the company asked an architect to recommend a QoS solution. The customer is currently using a CBWFQ policy to manage traffic on an internet connection with a speed of 100 Mbps. Which link-capacity limit must the architect choose for strictpriority for the real-time traffic?

25 Mbps

50 Mbps

33 Mbps

75 Mbps

Show Answer Comment (0)

Question 197

A company plans to transition to IPv6. They will link their IPv4 addresses to the lowest significant bits of the new Ipv6 addresses. A network administrator with an employee id: 4264:42:116 is preparing a mapping schema for the new IPv6 addresses. Which address does the 172.16.10.0/24 network translate to?

2001:db8:abcd::ac10:a00/120

2001:db8:abcd:172:16:10::/96

2001:db8:abcd:11d8:a00/120

2001:db8:ac10:0a00::/64

Show Answer Comment (0)
