Because MAB uses the MAC address as a username and password, you should make sure that the RADIUS server can differentiate MAB requests from other types of requests for network access. This precaution will prevent other clients from attempting to use a MAC address as a valid credential.

Cisco switches uniquely identify MAB requests by setting Attribute 6 (Service-Type) to 10 (Call-Check) in a MAB Access- Request message. Therefore, you can use Attribute 6 to filter MAB requests at the RADIUS server.

Reference: https://www.cisco.com/c/en/us/products/collateral/ios-nx-os-software/identity-basednetworkingservices/config_guide_c17-663759.html

Dynamic ARP inspection (DAI) is a security feature that validates ARP packets in a network. It intercepts, logs, and discards ARP packets with invalid IP-to-MAC address bindings. This capability protects the network from certain man-in- the-middle attacks. After enabling DAI, all ports become untrusted ports.

https://www.cisco.com/c/en/us/td/docs/ios-xml/ios/security/s1/sec-s1-xe-3se-3850-cr-book/sec-s1-xe-3se-3850-cr-book_chapter_01.html#wp3404908137Displaying the Summary of All Auth Manager Sessions on the SwitchEnter the following:

Switch# show authentication sessions

Interface MAC Address Method Domain Status Session ID

Gi1/48 0015.63b0.f676 dot1x DATA Authz Success 0A3462B1000000102983C05C

Gi1/5 000f.23c4.a401 mab DATA Authz Success 0A3462B10000000D24F80B58

Gi1/5 0014.bf5d.d26d dot1x DATA Authz Success 0A3462B10000000E29811B94

The syntax of this command is shown below: snmp-server group [group-name {v1 | v2c | v3 [auth | noauth | priv]}] [read read-view] [write writeview] [notify notify-view] [access access-list] The command above restricts which IP source addresses are allowed to access SNMP functions on the router. You could restrict SNMP access by simply applying an interface ACL to block incoming SNMP packets that don't come from trusted servers. However, this would not be as effective as using the global SNMP commands shown in this recipe. Because you can apply this method once for the whole router, it is much simpler than applying ACLs to block SNMP on all interfaces separately. Also, using interface

ACLs would block not only SNMP packets intended for this router, but also may stop SNMP packets that just happened to be passing through on their way to some other destination device.

The profiling service issues the change of authorization in the following cases:

– Endpoint deleted—When an endpoint is deleted from the Endpoints page and the endpoint is disconnected or removed from the network.

An exception action is configured—If you have an exception action configured per profile that leads to an unusual or an unacceptable event from that endpoint. The profiling service moves the endpoint to the corresponding static profile by issuing a CoA.

– An endpoint is profiled for the first time—When an endpoint is not statically assigned and profiled for the first time; for example, the profile changes from an unknown to a known profile.

+ An endpoint identity group has changed—When an endpoint is added or removed from an endpoint identity group that is used by an authorization policy.

The profiling service issues a CoA when there is any change in an endpoint identity group, and the endpoint identity group is used in the authorization policy for the following:

++ The endpoint identity group changes for endpoints when they are dynamically profiled ++ The endpoint identity group changes when the static assignment flag is set to true for a dynamic endpoint – An endpoint profiling policy has changed and the policy is used in an authorization policy—When an endpoint profiling policy changes, and the policy is included in a logical profile that is used in an authorization policy. The endpoint profiling policy may change due to the profiling policy match or when an endpoint is statically assigned to an endpoint profiling policy, which is associated to a logical profile. In both the cases, the profiling service issues a CoA, only when the endpoint profiling policy is used in an authorization policy.

Reference: https://www.cisco.com/c/en/us/td/docs/security/ise/2-1/admin_guide/b_ise_admin_guide_21/ b_ise_admin_guide_20_chapter_010100.html
