The command "snmp-server user user-name group-name [remote ip-address [udp-port port]] {v1 | v2c | v3 [encrypted] [auth {md5 | sha} auth-password]} [access access-list]" adds a new user (in this case "andy") to an SNMPv3 group (in this case group name "myv3") and configures a password for the user.

In the "snmp-server host" command, we need to:

+ Specify the SNMP version with key word "version {1 | 2 | 3}"

+ Specify the username ("andy"), not group name ("myv3").

Note: In "snmp-server host inside …" command, "inside" is the interface name of the ASA interface through which the NMS (located at 10.255.254.1) can be reached.

The telemetry information consists of three types of data:

+ Flow information: This information contains details about endpoints, protocols, ports, when the flow started, how long the flow was active, etc.

+ Interpacket variation: This information captures any interpacket variations within the flow.

Examples include variation in Time To Live (TTL), IP and TCP flags, payload length, etc + Context details: Context information is derived outside the packet header. It includes details about variation in buffer utilization, packet drops within a flow, association with tunnel endpoints, etc.

Reference: https://www.cisco.com/c/dam/global/en_uk/products/switches/cisco_nexus_9300_ex_platform_switches_white_paper_uki.pdf

DNS Tunneling is a method of cyber attack that encodes the data of other programs or protocols in DNS queries and responses. DNS tunneling often includes data payloads that can be added to an attacked DNS server and used to control a remote server and applications.

Domain name system (DNS) is the protocol that translates human-friendly URLs, such as securitytut.com, into IP addresses, such as 183.33.24.13. Because DNS messages are only used as the beginning of each communication and they are not intended for data transfer, many organizations do not monitor their DNS traffic for malicious activity. As a result, DNS-based attacks can be effective if launched against their networks. DNS tunneling is one such attack.

An example of DNS Tunneling is shown below:

The attacker incorporates one of many open-source DNS tunneling kits into an authoritative DNS nameserver (NS) and malicious payload.

2. An IP address (e.g. 1.2.3.4) is allocated from the attacker's infrastructure and a domain name (e.g. attackerdomain.com) is registered or reused. The registrar informs the top-level domain (.com) nameservers to refer requests for attackerdomain.com to ns.attackerdomain.com, which has a DNS record mapped to 1.2.3.4 3. The attacker compromises a system with the malicious payload. Once the desired data is obtained, the payload encodes the data as a series of

32 characters (0-9, A-Z) broken into short strings

(3KJ242AIE9, P028X977W,…).

4. The payload initiates thousands of unique DNS record requests to the attacker's domain with each string as a part of the domain name (e.g. 3KJ242AIE9.attackerdomain.com). Depending on the attacker's patience and stealth, requests can be spaced out over days or months to avoid suspicious network activity.

5. The requests are forwarded to a recursive DNS resolver. During resolution, the requests are sent to the attacker's authoritative DNS nameserver, 6. The tunneling kit parses the encoded strings and rebuilds the exfiltrated data.

Reference: https://learn-umbrella.cisco.com/i/775902-dns-tunneling/0

Spero analysis examines structural characteristics such as metadata and header information in executable files. After generating a Spero signature based on this information, if the file is an eligible executable file, the device submits it to the Spero heuristic engine in the AMP cloud. Based on the Spero signature, the Spero engine determines whether the file is malware.

Reference:

https://www.cisco.com/c/en/us/td/docs/security/firepower/60/configuration/guide/fpmc-configguidev60/Reference_a_wrapper_Chapter_topic_here.html-> Spero analysis only uploads the signature of the (executable) files to the AMP cloud. It does notupload thewhole file. Dynamic analysis sends files to AMP ThreatGrid.

Dynamic Analysis submits (the whole) files to Cisco Threat Grid (formerly AMP Threat Grid). Cisco Threat Grid runs the file in a sandbox environment, analyzes the file's behavior to determine whether the file is malicious, and returns a threat score that indicates the likelihood that a file contains malware. From the threat score, you can view a dynamic analysis summary report with the reasons for the assigned threat score. You can also look in Cisco Threat Grid to view detailed reports for files that your organization submitted, as well as scrubbed reports with limited data for files that your organization did not submit.

Local malware analysis allows a managed device to locally inspect executables, PDFs, office documents, and other types of files for the most common types of malware, using a detection rule set provided by the Cisco Talos Security

Intelligence and Research Group (Talos). Because local analysis does not query the AMP cloud, and does not run the file, local malware analysis saves time and system resources. -> Malware analysis does not upload files to anywhere, it only checks the files locally.

There is no sandbox analysis feature, it is just a method of dynamic analysis that runs suspicious files in a virtual machine.
