Explanation:

You need to configure the Network Security Group that is associated with subnet0.

1. In the Azure portal, type Virtual Networks in the search box, select Virtual Networks from the search results then select VNET1. Alternatively, browse to Virtual Networks in the left navigation pane.

2. In the properties of VNET1, click on Subnets. This will display the subnets in VNET1 and the Network Security Group associated to each subnet. Note the name of the Network Security Group associated to Subnet0.

3. Type Network Security Groups into the search box and select the Network Security Group associated with Subnet0.

4. In the properties of the Network Security Group, click on Inbound Security Rules.

5. Click the Add button to add a new rule.

6. In the Source field, select Service Tag.

7. In the Source Service Tag field, select Internet.

8. Leave the Source port ranges and Destination field as the default values (* and All).

9. In the Destination port ranges field, enter 7777.

10.Change the Protocol to TCP.

11.Leave the Action option as Allow.

12.Change the Priority to 100.

13.Change the Name from the default Port_8080 to something more descriptive such as Allow_TCP_7777_from_Internet. The name cannot contain spaces.

14.Click the Add button to save the new rule.

Explanation:

Enable diagnostic resource logging for the NSG. You can use the Azure portal, Azure PowerShell, or the Azure CLI to do this. You need to select the Rule counter category under Logs and choose the Iogs31330471 storage account as the destination.

Configure the retention policy for the storage account to keep the logs for 30 days. You can use the Azure portal, Azure PowerShell, or the Azure CLI to do this. You need to specify the days parameter as 30 for the Set-AzStorageServiceProperty cmdlet or the az storage logging update command.

View and analyze the logs in the storage account. You can use any tool that can read JSON files, such as Azure Storage Explorer or Visual Studio Code. You can also export the logs to any visualization tool, SIEM solution, or IDS of your choice

Explanation:

Create and register an Azure AD application. You can use the Azure portal, Azure PowerShell, or the Azure CLI to do this. You need to specify a name, such as SQLServerCTP1, and select the supported account types, such as Accounts in this organization directory only.

Grant application permissions. You can use the Azure portal, Azure PowerShell, or the Azure CLI to do this. You need to assign the Directory.Read.All permission to the application and grant admin consent for your organization.

Create and assign a certificate. You can use the Azure portal, Azure PowerShell, or the Azure CLI to do this. You need to create a self-signed certificate and upload it to the application. You also need to store the certificate in Azure Key Vault and grant access policies to the application and your SQL Server.

Configure Azure AD authentication for SQL Server through Azure portal. You can use the Azure portal to do this. You need to select your SQL Server resource and enable Azure AD authentication. You also need to select your Azure AD application as the Azure AD admin for your SQL Server.

Create logins and users. You can use SSMS or Transact-SQL to do this. You need to connect to your SQL Server as the Azure AD admin and create a login for Danny-31330471. You also need to create a user for Danny-31330471 in each database that he needs access to.

Connect with a supported authentication method. You can use SSMS or SqlClient to do this. You need to specify the Authentication connection property in the connection string as Active Directory Password or Active Directory Integrated. You also need to provide the username and password of Danny-31330471.

Grant permission to the application that is used to deploy the resources to access the secrets in the key vault. You can use the Azure portal, Azure PowerShell, or the Azure CLI to do this. You need to assign the Key Vault Secrets User role to the application at the scope of the key vault or individual secrets.

Enable template deployment for the key vault. You can use the Azure portal, Azure PowerShell, or the Azure CLI to do this. You need to set the enabledForTemplateDeployment property of the key vault to true.

Reference the secrets in the template by using their resource ID. You can use the listSecrets function to get the resource ID of a secret in the key vault. You need to specify the name of the key vault and the name of the secret as parameters.

Deploy the template by using Azure PowerShell, Azure CLI, or REST API. You can use the NewAzResourceGroupDeployment cmdlet, the az deployment group create command, or the Deployments - Create Or Update REST API to do this. You need to provide the template file or URI

and any required parameters.

Explanation:

Create an Azure Resource Manager service principal. You can use the Azure portal, Azure PowerShell, or the Azure CLI to do this. You need to specify a name and a role for the service principal, such as Contributor.

Grant permission to the service principal to access the secrets in the key vault. You can use the Azure portal, Azure PowerShell, or the Azure CLI to do this. You need to assign the Key Vault Secrets User role to the service principal at the scope of the key vault or individual secrets.

Enable template deployment for the key vault. You can use the Azure portal, Azure PowerShell, or the Azure CLI to do this. You need to set the enabledForTemplateDeployment property of the key vault to true.

Reference the secrets in the template by using their resource ID. You can use the listSecrets function to get the resource ID of a secret in the key vault. You need to specify the name of the key vault and the name of the secret as parameters.

Deploy the template by using Azure PowerShell, Azure CLI, or REST API. You can use the NewAzResourceGroupDeployment cmdlet, the az deployment group create command, or the Deployments - Create Or Update REST API to do this. You need to provide the template file or URI

and any required parameters. You also need to provide the credentials of the service principal.

Explanation:

Configure the firewall settings for the SQL server. You can use the Azure portal, Azure PowerShell, or the Azure CLI to do this. You need to add a firewall rule that allows inbound traffic from the IP address range of the Subnet0 subnet. You also need to disable the option to allow Azure services and resources to access this server.

Configure the network settings for the SQL server. You can use the Azure portal, Azure PowerShell, or the Azure CLI to do this. You need to enable service endpoints for SQL Server on the Subnet0 subnet.

You also need to add a virtual network rule that links the SQL server to the Subnet0 subnet.

Configure the connection settings for the SQL server. You can use SQL Server Management Studio or Transact-SQL to do this. You need to enable remote server connections and specify a TCP port for listening. You also need to configure SQL Server Authentication or Azure Active Directory

Authentication for connecting to the SQL server.

Explanation:

Enable Web Application Firewall (WAF) for the application gateway. You can use the Azure portal, Azure PowerShell, or the Azure CLI to do this. You need to select a WAF policy and a WAF mode for the application gateway. You can choose a predefined policy or create a custom policy with your own rules and exclusions.

Configure WAF policy settings. You can use the Azure portal, Azure PowerShell, or the Azure CLI to do this. You need to select the managed rulesets and rule groups that you want to enable or disable for the WAF policy. You can also configure custom rules to match specific patterns or conditions and take actions such as blocking or logging requests.

Monitor WAF logs. You can use different types of logs in Azure to manage and troubleshoot the application gateway and the WAF policy. You can access some of these logs through the portal, such as metrics and health probes. You can also export the logs to Azure Storage, Event Hubs, or Log Analytics and view them in different tools, such as Azure Monitor, Excel, or Power BI.
