Which of the following addresses can be used on a public network? (Choose two.)

A.
172.30.0.1/16
A.
172.30.0.1/16
Answers
B.
127.254.11.15/16
B.
127.254.11.15/16
Answers
C.
172.15.12.7/16
C.
172.15.12.7/16
Answers
D.
193.168.10.4/16
D.
193.168.10.4/16
Answers
Suggested answer: C, D

Different network segments can be in the same OSPF area and the same network segment can be in different OSPF areas.

A.
True
A.
True
Answers
B.
False
B.
False
Answers
Suggested answer: B

What is the maximum bits of a Class B address can be used for subnet?

A.
8
A.
8
Answers
B.
14
B.
14
Answers
C.
16
C.
16
Answers
D.
22
D.
22
Answers
Suggested answer: B

A company reserves the network segment 172.29.100.0/26 for some remote small-scale sites and each site has 5 IP devices to connect to this network segment.

Which of the following VLSM masks can be used to provide minimum number of hosts to meet such a requirement?

A.
/27
A.
/27
Answers
B.
/28
B.
/28
Answers
C.
/29
C.
/29
Answers
D.
/30
D.
/30
Answers
Suggested answer: C

Which of the following network or link type is not the basic network or link type defined in OSPF?

A.
P2P
A.
P2P
Answers
B.
P2MP
B.
P2MP
Answers
C.
Broadcast
C.
Broadcast
Answers
D.
Virtual link
D.
Virtual link
Answers
Suggested answer: D

An OSPF neighbor relationship fails to be established and the display ospf error command output is as follows.

Which of the following is the possible cause?

A.
Router IDs conflict.
A.
Router IDs conflict.
Answers
B.
Area IDs are mismatched.
B.
Area IDs are mismatched.
Answers
C.
Network masks are inconsistent.
C.
Network masks are inconsistent.
Answers
D.
Authentication types are inconsistent.
D.
Authentication types are inconsistent.
Answers
Suggested answer: D

Which of the following statements about LACP are true? (Choose two.)

A.
It complies with IEEE 802.3az.
A.
It complies with IEEE 802.3az.
Answers
B.
A device enabled with LACP exchanges Link Aggregation Control Protocol Data Units (LACPDUs) with its peer.
B.
A device enabled with LACP exchanges Link Aggregation Control Protocol Data Units (LACPDUs) with its peer.
Answers
C.
Devices at both ends determine the active interface according to the interface priority of the active device.
C.
Devices at both ends determine the active interface according to the interface priority of the active device.
Answers
Suggested answer: B, C

Which of the following are end-to-end link protection modes? (Choose three.)

A.
1: 1
A.
1: 1
Answers
B.
M: N
B.
M: N
Answers
C.
N: 1
C.
N: 1
Answers
D.
1+1
D.
1+1
Answers
Suggested answer: A, B, D

An OSPF neighbor relationship fails to be established and the display ospf error command output is as follows.

Which of the following is the possible cause?

A.
Router IDs conflict.
A.
Router IDs conflict.
Answers
B.
Area IDs are mismatched.
B.
Area IDs are mismatched.
Answers
C.
Network masks are inconsistent.
C.
Network masks are inconsistent.
Answers
D.
Authentication types are inconsistent.
D.
Authentication types are inconsistent.
Answers
Suggested answer: A

Which of the following statements about BFD Echo packets are true? (Choose two.)

A.
The Echo packet format is not defined in BFD.
A.
The Echo packet format is not defined in BFD.
Answers
B.
The Echo packet format is defined in BFD.
B.
The Echo packet format is defined in BFD.
Answers
C.
Echo packets use UDP destination port number 3785.
C.
Echo packets use UDP destination port number 3785.
Answers
D.
Echo packets use UDP destination port number 3784.
D.
Echo packets use UDP destination port number 3784.
Answers
Suggested answer: A, C
