Question 251

(0)

Which of the following technologies can be used to improve the MPLS BGP VPN reliability?

Question 252

(0)

Typically, users within a VPN only communicate with other users in the same VPN. They cannot communicate with users on the Internet or access the Internet. Many VPN sites, however, may need to acce

Question 253

(0)

If a multicast group has multiple receivers and the administrator enables the IGMP snooping function on the switch connected to the receivers, how do the receivers respond after receiving General Qu

Question 254

(0)

Which MAC address corresponds to the multicast IP address 229.130.130.1?

Question 255

(0)

Which of the following statements regarding the Register message on a PIM-SM network are true?

Question 256

(0)

IPSG static binding entries can be configured, or they can be generated when IPSG and DHCP Snooping are used together.

Question 257

(0)

To configure AAA, you need to configure a RADIUS server as follows: [Huawei]radius-server template EXAM [Huawei-radius-EXAM]radius-server shared-key cipher HUAwei123 [Huawei-radius-EXAM]radius-se

Question 258

(0)

As shown in the figure, Department A of Branch 1 can access the Internet, and Department B can access headquarters resources only through the encrypted VPN. You can configure a NAT policy on the egr

Question 259

(0)

In traffic policing, dual buckets at dual rates are used. The number of tokens in bucket C is TC, and the number of tokens in bucket P is TP. When a packet with a length of B is received, which of t

Question 260

(0)

The DSCP value of VoIP traffic on Huawei network devices needs to be set to EF. According to the RFC about DSCP, which value should EF be set to?

Question 251

Which of the following technologies can be used to improve the MPLS BGP VPN reliability?

VPN GR

FRR for private IP routes between Pes and CEs

VPN FRR

CE dual-homing networking at the access layer

Show Answer Comment (0)

Question 252

Typically, users within a VPN only communicate with other users in the same VPN. They cannot communicate with users on the Internet or access the Internet.

Many VPN sites, however, may need to access the Internet. Which of the following statements regarding interconnection between the VPN and the Internet are true?

The interconnection between the VPN and the Internet can be implemented on the PE. However, the implementation is complex and may bring security risks.The PE is vulnerable to DoS attacks from the Internet.

Directly connect the CE to the Internet on the user side. Each user site can independently access the Internet. That is, a default route destined for the Internet is configured on the CE of each site.

Configure the PE to send a default route destined for the Internet to the CE, and add a default route destined for the Internet gateway to the VPN instance routing table.

Isolating public network routes and VPN routes on the user side is simple, secure, and reliable.

Show Answer Comment (0)

Question 253

If a multicast group has multiple receivers and the administrator enables the IGMP snooping function on the switch connected to the receivers, how do the receivers respond after receiving General Query messages from the querier?

Only the receiver whose response timer expires firstly sends a Report message

All receivers send Report messages

All receivers send Report messages only when IGMPv1 is run

All receivers send Report messages only when IGMPv2 is run

Show Answer Comment (0)

Question 254

Which MAC address corresponds to the multicast IP address 229.130.130.1?

01-00-5E-82-82-01

00-00-5E-02-82-01

01-00-5E-02-82-01

00-00-5E-82-82-01

Show Answer Comment (0)

Question 255

Which of the following statements regarding the Register message on a PIM-SM network are true?

The Register message is sent from a source DR

The Register message is sent to the RP in unicast mode

The Register message is sent from a receiver DR

The RP learns multicast source information from the Register message

Show Answer Comment (0)

Question 256

IPSG static binding entries can be configured, or they can be generated when IPSG and DHCP Snooping are used together.

TRUE

FALSE

Show Answer Comment (0)

Question 257

To configure AAA, you need to configure a RADIUS server as follows:

[Huawei]radius-server template EXAM

[Huawei-radius-EXAM]radius-server shared-key cipher HUAwei123

[Huawei-radius-EXAM]radius-server authentication 10.7.66.66 1812

[Huawei-radius-EXAM]radius-server authorization 10.7.66.66 1812

[Huawei-radius-EXAM]radius-server accounting 10.7.66.66 1813

[Huawei-radius-EXAM]radius-server retransmit 2

TRUE

FALSE

Show Answer Comment (0)

Question 258

As shown in the figure, Department A of Branch 1 can access the Internet, and Department B can access headquarters resources only through the encrypted VPN. You can configure a NAT policy on the egress device in Branch 1 to allow Department A to still access the Internet, and configure an IPsec VPN (ESP protocol) in tunnel mode for Department B to allow Department B to access the headquarters.

TRUE

FALSE

Show Answer Comment (0)

Question 259

In traffic policing, dual buckets at dual rates are used. The number of tokens in bucket C is TC, and the number of tokens in bucket P is TP. When a packet with a length of B is received, which of the following statements are true?

If (TP-B) and (TC-B) are larger than 0, the packet is marked green

If (TP-B) is larger than 0 and (TC-B) is smaller than 0, the packet is marked yellow

If (TP-B) is larger than 0 and (TC-B) is smaller than 0, the packet is marked green

If (TP-B) and (TC-B) are smaller than 0, the packet is marked red

Show Answer Comment (0)
