ARP and ND Suppression are features of ArubaOS-CX that reduce the broadcast traffic on EVPN VXLAN networks1. ARP and ND Suppression enable the switch to reply to ARP and ND requests with information present in the local ARP and neighbor cache, instead of flooding them to all VTEPs1. This reduces the bandwidth consumption and improves the network performance1. When ARPSuppression is enabled, the switch replies to ARP requests with information present in the local ARP Table2. Therefore, this statement about ARP and ND Suppression is true, and the correct answer is yes. For more information on ARP and ND Suppression, refer to the Aruba Data Center Network Specialist (ADCNS) certification datasheet3 and the EVPN VXLAN Guide for your switch model1.

ARP and ND Suppression are features of ArubaOS-CX that reduce the broadcast traffic on EVPN VXLAN networks1. ARP and ND Suppression enable the switch to reply to ARP and ND requests with information present in the local ARP and neighbor cache, instead of flooding them to all VTEPs1. This reduces the bandwidth consumption and improves the network performance1. ARP-Suppression and ND-Suppression can be enabled or disabled independently1. They do not have to be enabled together1. Therefore, this statement about ARP and ND Suppression is false, and the correct answer is no. For more information on ARP and ND Suppression, refer to the Aruba Data Center Network

Specialist (ADCNS) certification datasheet3 and the EVPN VXLAN Guide for your switch model1.

Based on the exhibits, Switch-1 has a trunk port on 1/1/1 that allows VLANs 10 and 20. Switch-2 has an access port on 1/1/2 that belongs to VLAN 10. Switch-3 has an access port on 1/1/3 that belongs to VLAN 20. If a broadcast arrives with a VLAN 10 tag on 1/1/1 on Switch-1, Switch-1 does not drop the frame. Instead, Switch-1 forwards the frame to all ports that belong to VLAN 10, which includes the trunk port 1/1/2 and the access port 1/1/4. Switch-2 receives the frame on its access port 1/1/2 and forwards it to all ports in VLAN 10, which includes the access port 1/1/5. Switch-3 does not receive the frame because it is not in VLAN 10. Therefore, this is not how the switch handles the traffic, and the correct answer is no.

Priority Flow Control (PFC) is a feature of ArubaOS-CX that eliminates packet loss due to congestion on a network link1. PFC uses IEEE 802.1Qbb standard to pause traffic on a per-priority basis1. PFC can be configured to operate in symmetric or asymmetric mode1. Symmetric mode applies PFC to both the receiving and sending of pause frames1. Asymmetric mode applies PFC to either the receiving or sending of pause frames1. To configure PFC on an interface, you need to enable flow control with a priority value and configure a DCBX application priority on the interface1. A DCBX application priority maps a traffic class to a priority group and enables the switch to negotiate PFC parameters with the peer device1. Therefore, this is a requirement for implementing PFC on an ArubaOS-CX switch interface, and the correct answer is yes. For more information on PFC and DCBX, refer to the Aruba Data Center Network Specialist (ADCNS) certification datasheet2 and the QoS Guide for your switch model1.

Deploying Aruba 83xx switches as core switches for very large three-tier data center networks is how you should position switches in the ArubaOS-CX portfolio for data center networks. The Aruba 83xx switches are designed for data center spine or core roles, and they provide high performance, scalability, and resiliency. They can support very large three-tier data center networks with up to 512 leaf switches using VSX2.

Configuring trust of CoS on the interface is a requirement for implementing Priority Flow Control (PFC) on an ArubaOS-CX switch interface. PFC is a feature that allows a switch to pause traffic on a per-class basis using IEEE 802.1Qbb frames. To use PFC, the switch must trust the CoS values in the incoming frames and map them to priority groups and queues1.

The guard interval is set in units of seconds and is used to prevent frequent topology changes due to a link going up and down is not a guideline for configuring timers for Ethernet Ring Protection Switching (ERPS) on an ArubaOS-CX switch. The guard interval is set in units of milliseconds, not seconds, and it is used to prevent false ring failures due to short link outages or flapping1.

Both ARP-Suppression and ND-Suppression are disabled by default is not a true statement about ARP and ND Suppression. ARP-Suppression is enabled by default on ArubaOS-CX switches, while NDSuppression is disabled by default1. ARP-Suppression and ND-Suppression are features that reduce broadcast traffic on VXLAN networks by using a local ARP/ND cache on each switch instead of flooding ARP/ND requests to all VXLAN tunnel endpoints (VTEPs)1.
