Answer: Allow System APIs to return data that is NOT currently required by the identified Process or Experience APIs.

*****************************************

>> All customizations for the end-user application should be handled in "Experience API" only. Not in Process API

>> We should use tiered approach but NOT always by creating exactly one API for each of the 3 layers. Experience APIs might be one but Process APIs and System APIs are often more than one.

System APIs for sure will be more than one all the time as they are the smallest modular APIs built in front of end systems.

>> Process APIs can call System APIs as well as other Process APIs. There is no such anti-design pattern in API-Led connectivity saying Process APIs should not call other Process APIs.

So, the right answer in the given set of options that makes sense as per API-Led connectivity principles is to allow System APIs to return data that is NOT currently required by the identified Process or Experience APIs. This way, some future Process APIs can make use of that data from System APIs and we need NOT touch the System layer APIs again and again.

Answer: The API policy is defined in API Manager for a specific API instance, and then ONLY applied to the specific API instance.

*****************************************

>> Once our API specifications are ready and published to Exchange, we need to visit API Manager and register an API instance for each API.

>> API Manager is the place where management of API aspects takes place like addressing NFRs by enforcing policies on them.

>> We can create multiple instances for a same API and manage them differently for different purposes.

>> One instance can have a set of API policies applied and another instance of same API can have different set of policies applied for some other purpose.

>> These APIs and their instances are defined PER environment basis. So, one need to manage them seperately in each environment.

>> We can ensure that same configuration of API instances (SLAs, Policies etc..) gets promoted when promoting to higher environments using platform feature. But this is optional only. Still one can change them per environment basis if they have to.

>> Runtime Manager is the place to manage API Implementations and their Mule Runtimes but NOT APIs itself. Though API policies gets executed in Mule Runtimes, We CANNOT enforce API policies in Runtime Manager. We would need to do that via API Manager only for a cherry picked instance in an environment.

So, based on these facts, right statement in the given choices is - "The API policy is defined in API Manager for a specific API instance, and then ONLY applied to the specific API instance".

Reference: https://docs.mulesoft.com/api-manager/2.x/latest-overview-concept

Answer: When the response time of API invocations exceeds a threshold *****************************************

>> Alerts can be setup for all the given options using the default Anypoint Platform functionality

>> However, the question insists on an alert whose conditions depend on the end-to-end request processing of the API implementation.

>> Alert w.r.t "Response Times" is the only one which requires end-to-end request processing of API implementation in order to determine if the threshold is exceeded or not.

Reference: https://docs.mulesoft.com/api-manager/2.x/using-api-alerts

Answer: 8082

*****************************************

>> 8091 and 8092 ports are to be used when keeping your HTTP and HTTPS app private to the LOCALVPC respectively.

>> Above TWO ports are not for Shared AWS VPC/ Shared Worker Cloud.

>> 8081 is to be used when exposing your HTTP endpoint app to the internet through Shared LB

>> 8082 is to be used when exposing your HTTPS endpoint app to the internet through Shared LBSo, API invocations should be sent to port 8082 when calling this HTTPS based app.

References:

https://docs.mulesoft.com/runtime-manager/cloudhub-networking-guide

https://help.mulesoft.com/s/article/Configure-Cloudhub-Application-to-Send-a-HTTPS-Request-Directly-to-Another-Cloudhub-Application

https://help.mulesoft.com/s/question/0D52T00004mXXULSA4/multiple-http-listerners-oncloudhub-one-with-port-9090

https://www.folkstalk.com/2019/11/mulesoft-integration-and-platform.html

Explanation:

Answer: To invoke OAuth 2.0-protected APIs managed by Anypoint Platform, API clients must submit access tokens issued by that same Identity Provider *****************************************

>> It is NOT necessary that single sign-on is required to sign in to Anypoint Platform because we are using an external Identity Provider for Client Management

>> It is NOT necessary that all APIs managed by Anypoint Platform must be protected by SAML 2.0 policies because we are using an external Identity Provider for Client Management

>> Not TRUE that the application network must include System APIs that interact with the Identity Provider because we are using an external Identity Provider for Client Management Only TRUE statement in the given options is - "To invoke OAuth 2.0-protected APIs managed by Anypoint Platform, API clients must submit access tokens issued by that same Identity Provider" References:

https://docs.mulesoft.com/api-manager/2.x/external-oauth-2.0-token-validation-policy

https://blogs.mulesoft.com/dev/api-dev/api-security-ways-to-authenticate-and-authorize/

Answer: GET, OPTIONS, HEAD

http://restcookbook.com/HTTP%20Methods/idempotency/

Answer: Persistent Object Store

*****************************************

>> Redis distributed cache is performant but NOT out-of-the-box solution in Anypoint Platform

>> File-storage is neither performant nor out-of-the-box solution in Anypoint Platform

>> java.util.WeakHashMap needs a completely custom implementation of cache from scratch using Java code and is limited to the JVM where it is running. Which means the state in the cache is not worker aware when running on multiple workers. This type of cache is local to the worker. So, this is neither out-of-the-box nor worker-aware among multiple workers on cloudhub.

https://www.baeldung.com/java-weakhashmap

>> Persistent Object Store is an out-of-the-box solution provided by Anypoint Platform which is performant as well as worker aware among multiple workers running on CloudHub.

https://docs.mulesoft.com/object-store/

So, Persistent Object Store is the right answer.

Answer: By refining the response definitions by adding the x-ratelimit-* response headers with description, type, and example

*****************************************

References:

https://docs.mulesoft.com/api-manager/2.x/rate-limiting-and-throttling#response-headers

https://docs.mulesoft.com/api-manager/2.x/rate-limiting-and-throttling-sla-basedpolicies#response-headers

Answer: Apply a JSON threat protection policy to all APIs to detect potential threat vectors *****************************************

>> Usually, if the APIs are designed and developed for specific consumers (known consumers/customers) then we would IP Whitelist the same to ensure that traffic only comes from them.

>> However, as this scenario states that the APIs are publicly available and being used by so many mobile and web applications, it is NOT possible to identify and blacklist all possible bad actors.

>> So, JSON threat protection policy is the best chance to prevent any bad JSON payloads from such bad actors.
