DELL D-RP-DY-A-24 Practice Test - Questions Answers, Page 4

Initiator Identification: Unisphere identifies a RecoverPoint initiator with VNX through RPA registration by using the World Wide Name (WWN) of the RecoverPoint Appliance (RPA).

Registration Process: During the registration process, the RPA's WWN is used to uniquely identify and authenticate the RPA within the storage network.

Unisphere Integration: Once registered, the RPA can be managed and monitored through Unisphere, which is the management interface for VNX and other EMC storage systems.

For detailed procedures on RPA registration and integration with Unisphere, refer to the Dell RecoverPoint deployment documentation or the Unisphere for RecoverPoint user guide12.

Access the CLI: Use the boxmgmt account to log into the Command Line Interface (CLI) of the RecoverPoint Appliance.

Run the Command: Execute the set_user name=admin password= command to initiate the password reset process.

Set New Password: Follow the prompts to set a new password for the admin user.

This process is used when the admin password has been lost and needs to be reset. It is important to follow the correct syntax and procedure to ensure the security and integrity of the system1.

When changing from physical RPAs to vRPAs in a RecoverPoint with VNX(SE) environment, the licensing remains the same and no additional action is required. The existing licenses can be applied to the virtual RPAs without the need for new licenses.

Dell RecoverPoint for Virtual Machines 6.0.1 vSphere HTML5 Plugin Administrator's Guide, Chapter on licensing and virtual RPA deployment.

Access the Cluster Management Interface: Use a web browser to navigate to the RecoverPoint Cluster Management IP address.

Navigate to the Load Statistics: Append /info/long_term_statistics to the Cluster Management IP in the browser's address bar.

View the Report: The RecoverPoint Cluster Load report can be viewed on this page, which provides long-term statistics including load information.

This method allows administrators to retrieve historical load data even if they did not capture the output at the time the capture load command was run1.

RecoverPoint offers different configurations depending on the version and setup. For RecoverPoint EX/CL, it supports one production copy and up to six replicated copies. This allows for comprehensive data protection and disaster recovery solutions by maintaining multiple copies of data1.

For detailed information on the capabilities and limitations of the different RecoverPoint versions, please refer to the official Dell EMC RecoverPoint documentation1.

In order to perform dynamic resizing of a replication set, the requirement is:

B . Both production and the copies must be provisioned from an XtremIO array

Explanation: Dynamic resizing of a replication set requires both the production and replica copies to be provisioned from an XtremIO array. XtremIO's architecture supports this dynamic resizing capability, allowing administrators to adjust the size of the replication set without interrupting ongoing operations.

Reference: Dell RecoverPoint for Virtual Machines 6.0.1 vSphere HTML5 Plugin Administrator's Guide, Chapter on Managing Consistency Groups and Replication Sets.

Repository Volume: This is a special volume used by RecoverPoint for storing metadata about the system's configuration and the data it protects. It is essential for the operation of RecoverPoint and must be present on any array that is part of a RecoverPoint/EX cluster1.

Journal Volume: The journal volume is used to store changes to protected data. It allows RecoverPoint to recover data to any point in time within the journal window. Like the repository volume, it is a required component of a RecoverPoint/EX cluster1.

When adding volumes from an unlicensed array to a RecoverPoint/EX cluster, both repository and journal volumes are supported and required for the cluster's operation. The administrator must ensure that these volumes are properly configured to meet the system's requirements1.

The snapshots that represent the point-in-time images during normal replication are kept:

C . In the Journal pool on the XtremIO array containing the production volume

Explanation: In a RecoverPoint system, the Journal volumes are used to store the snapshots that represent the point-in-time images of the data being replicated. When both the production and copy volumes are provisioned from XtremIO arrays, the Journal pool on the XtremIO array containing the production volume is utilized to store these snapshots during normal replication.

Reference: Dell RecoverPoint for Virtual Machines 6.0.1 vSphere HTML5 Plugin Administrator's Guide, Chapter on Journal Sizing and Management.

Access the Symmetrix CLI: Log into the Symmetrix Command Line Interface (CLI) on the system where the VMAX LUNs are provisioned.

Run the Command: Execute the symdev -sid list -rp_tag command to list all devices with the RecoverPoint tag.

Verify Tagging: Review the output to confirm that the VMAX LUNs intended for use with RecoverPoint are correctly tagged.

This command is part of the EMC Symmetrix CLI and is specifically used to verify the tagging of LUNs for RecoverPoint, ensuring that they are recognized by the RecoverPoint system for replication purposes1.
