Question 51

Report Export Collapse

Which statements about the VLAN on S series switches are true? (Choose two.)

The VLAN IDs on the switch range from 1 to 4090.
The VLAN IDs on the switch range from 1 to 4090.
The switch has a default VLAN.
The switch has a default VLAN.
The priority value in the VLAN tag can be changed on the switch.
The priority value in the VLAN tag can be changed on the switch.
A VLAN tag contains one byte.
A VLAN tag contains one byte.
Suggested answer: B, C
asked 18/09/2024
Olusola Adebayo
46 questions

Question 52

Report Export Collapse

As shown in the figure, port 1 of switch A is configured with the Fixed mode, and other ports are configured with the Normal mode. The trunk interfaces allow all VLANs. Which VLANs are registered on port 1 of switch C? (Choose three.)

Huawei H12-224 image Question 52 31271 09182024192138000000

VLAN 1
VLAN 1
VLAN 5 to VLAN 10
VLAN 5 to VLAN 10
VLAN 15 to VLAN 20
VLAN 15 to VLAN 20
VLAN 25 to VLAN 30
VLAN 25 to VLAN 30
Suggested answer: A, B, C
asked 18/09/2024
Reza Mirabrishami
45 questions

Question 53

Report Export Collapse

In STP configuration, which statement about BPDUs is true?

BPDUs cannot be sent from the designated port.
BPDUs cannot be sent from the designated port.
BPDUs can be sent only from the designated port.
BPDUs can be sent only from the designated port.
BPDUs can be sent from any port.
BPDUs can be sent from any port.
None of the above.
None of the above.
Suggested answer: B
asked 18/09/2024
Luis Hernaiz
45 questions

Question 54

Report Export Collapse

Which statements about the relationship between GVRP and GARP are true? (Choose two.)

GVRP, GARP, and GMRP are the standards of the same type.
GVRP, GARP, and GMRP are the standards of the same type.
GVRP and GARP are defined by IEEE 802.1p.
GVRP and GARP are defined by IEEE 802.1p.
GVRP is based on GARP, and is an application of GARP.
GVRP is based on GARP, and is an application of GARP.
GVRP is a new definition of GARP.
GVRP is a new definition of GARP.
Suggested answer: B, C
asked 18/09/2024
sushma kc
44 questions

Question 55

Report Export Collapse

On an RSTP network, when an edge port is in protected state, what operation is performed after the edge port receives BPDUs?

The edge port forwards BPDUs.
The edge port forwards BPDUs.
The edge port discards BPDUs.
The edge port discards BPDUs.
The edge port is shut down.
The edge port is shut down.
The edge port obtains required information from BPDUs.
The edge port obtains required information from BPDUs.
Suggested answer: C
asked 18/09/2024
TienYai Ho
40 questions

Question 56

Report Export Collapse

The dot1x authentication-method command is used to set the 802.1x authentication mode. Which is the most secure authentication mode?

PAP
PAP
EAP
EAP
CHAP
CHAP
EAP-TTLS
EAP-TTLS
Suggested answer: C
asked 18/09/2024
Rambo Jhon
44 questions

Question 57

Report Export Collapse

When the topology of a network running RSTP changes, what happens after the change?

Flooding on the entire network.
Flooding on the entire network.
The aging time of MAC address entries is changed.
The aging time of MAC address entries is changed.
Some MAC address entries are deleted.
Some MAC address entries are deleted.
All of the above
All of the above
Suggested answer: C
asked 18/09/2024
Borisov Aleksandr
45 questions

Question 58

Report Export Collapse

The port isolation function can isolate the ports on the same switch.

True
True
False
False
Suggested answer: A
asked 18/09/2024
Neville Raposo
40 questions

Question 59

Report Export Collapse

Which statement about VLAN mapping is true?

The interface configured with VLAN mapping must be a hybrid interface.
The interface configured with VLAN mapping must be a hybrid interface.
The same VLANs on different interfaces cannot be mapped to different VLANs.
The same VLANs on different interfaces cannot be mapped to different VLANs.
Different VLANs on the same interface can be mapped to the same VLAN.
Different VLANs on the same interface can be mapped to the same VLAN.
Any types of interfaces can be configured with VLAN mapping.
Any types of interfaces can be configured with VLAN mapping.
Suggested answer: C
asked 18/09/2024
Jose Castillo
41 questions

Question 60

Report Export Collapse

Which problems on a single spanning tree network can be solved by MSTP? (Choose three.)

Traffic forwarding paths in some VLANs are faulty.
Traffic forwarding paths in some VLANs are faulty.
Traffic cannot be load balanced.
Traffic cannot be load balanced.
The second best path problem may occur.
The second best path problem may occur.
The network reliability cannot be improved.
The network reliability cannot be improved.
Suggested answer: A, B, C
asked 18/09/2024
Jose Osnayo
47 questions
