Cisco 300-430 Practice Test - Questions Answers, Page 6

List of questions

Question 51

Report Export Collapse

A wireless engineer needs to implement client tracking. Which method does the angle of arrival use to determine the location of a wireless device?

received signal strength

received signal strength

triangulation

triangulation

time distance of arrival

time distance of arrival

angle of incidence

angle of incidence

Suggested answer: D
Explanation:

Reference: https://www.cisco.com/c/en/us/td/docs/solutions/Enterprise/Mobility/WiFiLBSDG/wifich2.html

asked 07/10/2024
David Rossi
34 questions

Question 52

Report Export Collapse

Which two steps are needed to complete integration of the MSE to Cisco Prime Infrastructure to track the location of clients/rogues on maps? (Choose two.)

Synchronize access points with the MSE.

Synchronize access points with the MSE.

Add the MSE to Cisco Prime Infrastructure using the CLI credentials.

Add the MSE to Cisco Prime Infrastructure using the CLI credentials.

Add the MSE to Cisco Prime Infrastructure using the Cisco Prime Infrastructure communication credentials.

Add the MSE to Cisco Prime Infrastructure using the Cisco Prime Infrastructure communication credentials.

Apply a valid license for Wireless Intrusion Prevention System.

Apply a valid license for Wireless Intrusion Prevention System.

Apply a valid license for location tracking.

Apply a valid license for location tracking.

Suggested answer: D, E
asked 07/10/2024
Mahendra Belgaonkar
41 questions

Question 53

Report Export Collapse

An IT department receives a report of a stolen laptop and has information on the MAC address of the laptop. Which two settings must be set on the wireless infrastructure to determine its location?

(Choose two.)

Location History for Clients must be enabled on the MSE.

Location History for Clients must be enabled on the MSE.

Client location tracking must be enabled on the MSE.

Client location tracking must be enabled on the MSE.

Location History for Visitors must be enabled on the MSE.

Location History for Visitors must be enabled on the MSE.

Location History for Rogue APs & Rogue Clients must be enabled on the MSE.

Location History for Rogue APs & Rogue Clients must be enabled on the MSE.

Tracking optimization must be enabled on the WLC.

Tracking optimization must be enabled on the WLC.

Suggested answer: A, E
asked 07/10/2024
Pedro Pereira
43 questions

Question 54

Report Export Collapse

Refer to the exhibit.

Cisco 300-430 image Question 54 112387 10072024005858000000

An engineer needs to manage non-802.11 interference. What is observed in the output on PI?

At least one strong interferer is impacting connectivity at this site.

At least one strong interferer is impacting connectivity at this site.

Several light interferers are collectively impacting connectivity at this site.

Several light interferers are collectively impacting connectivity at this site.

The three individual clusters shown indicate poor AP placement.

The three individual clusters shown indicate poor AP placement.

RF at this site is unable to provide adequate wireless performance.

RF at this site is unable to provide adequate wireless performance.

Suggested answer: C
asked 07/10/2024
Vladimir Kornfeld
47 questions

Question 55

Report Export Collapse

After looking in the logs, an engineer notices that RRM keeps changing the channels for non-IEEE 802.11 interferers. After surveying the area, it has been decided that RRM should not change the channel. Which feature must be enabled to ignore non-802.11 interference?

Avoid Cisco AP Load

Avoid Cisco AP Load

Avoid Non-802.11 Noise

Avoid Non-802.11 Noise

Avoid Persistent Non-WiFi Interference

Avoid Persistent Non-WiFi Interference

Avoid Foreign AP Interference

Avoid Foreign AP Interference

Suggested answer: C
asked 07/10/2024
Marek Siwek
38 questions

Question 56

Report Export Collapse

Which two protocols are used to communicate between the Cisco MSE and the Cisco Prime Infrastructure network management software? (Choose two.)

HTTPS

HTTPS

Telnet

Telnet

SOAP

SOAP

SSH

SSH

NMSP

NMSP

Suggested answer: A, E
asked 07/10/2024
Ben Pike
42 questions

Question 57

Report Export Collapse

An engineer must configure MSE to provide guests access using social media authentication. Which service does the engineer configure so that guests use Facebook credentials to authenticate?

Social Connect

Social Connect

Client Connect

Client Connect

Visitor Connect

Visitor Connect

Guest Connect

Guest Connect

Suggested answer: A
asked 07/10/2024
Karl Newick
34 questions

Question 58

Report Export Collapse

A network engineer has been hired to perform a new MSE implementation on an existing network.

The MSE must be installed in a different network than the Cisco WLC. Which configuration allows the devices to communicate over NMSP?

Allow UDP/16113 port on the central switch.

Allow UDP/16113 port on the central switch.

Allow TCP/16113 port on the firewall.

Allow TCP/16113 port on the firewall.

Allow UDP/16666 port on the VPN router.

Allow UDP/16666 port on the VPN router.

Allow TCP/16666 port on the router.

Allow TCP/16666 port on the router.

Suggested answer: B
asked 07/10/2024
ADAMA DAO
43 questions

Question 59

Report Export Collapse

What is the default NMSP echo interval between Cisco MSE and a Wireless LAN Controller?

10 seconds

10 seconds

15 seconds

15 seconds

30 seconds

30 seconds

60 seconds

60 seconds

Suggested answer: B
Explanation:

Reference:

https://www.cisco.com/en/US/docs/wireless/mse/3350/6.0/CAS/configuration/guide/msecg_ch4_CAS.html

asked 07/10/2024
Enrique Villegas
41 questions

Question 60

Report Export Collapse

An engineer just added a new MSE to Cisco Prime Infrastructure and wants to synchronize the MSE with the Cisco 5520 WLC, located behind a firewall in a DMZ. It is noticed that NMSP messages are failing between the two devices.

Which traffic must be allowed on the firewall to ensure that the MSE and WLC are able to communicate using NMSP?

TCP 1613

TCP 1613

UDP 16113

UDP 16113

UDP 1613

UDP 1613

TCP 16113

TCP 16113

Suggested answer: D
asked 07/10/2024
Alex Amponsah
44 questions
Total 216 questions
