HP HPE6-A73 Practice Test - Questions Answers

List of questions

Question 1

Report Export Collapse

Examine the commands entered on an AOS-CX switch:

What is true regarding this configuration for traffic received on interface 100?

The default next-hop address supersedes the two preceding next-hop addresses
The default next-hop address supersedes the two preceding next-hop addresses
The traffic is always dropped is the next-hop addresses are unreachable
The traffic is always dropped is the next-hop addresses are unreachable
The traffic will be routed with the IP routing table entries if the next-hop addresses are unreachable
The traffic will be routed with the IP routing table entries if the next-hop addresses are unreachable
The next-hop address of 1.1.1.1 is overwritten by the next-hop address of 2.2.2.2
The next-hop address of 1.1.1.1 is overwritten by the next-hop address of 2.2.2.2
Suggested answer: C
Explanation:

"interface null: equivalent to the policy drop policing action. Any packets matching the class criteria for that policy entry will be dropped and not routed any further."

https://www.arubanetworks.com/techdocs/AOS-CX/10.05/HTML/5200-7300/index.html#GUIDDC7E5E47-8F31-4DE4-B257-1A68665B2AF4.htmlMore than one next hop can be assigned with an ACL and they work by priority (based on thesequence number: lower sequence number -> higher priority). So next-hop 2.2.2.2 will be used if1.1.1.1 is not reachable. If both are unreachable, then the packet will be routed looking at the defaultrouting table, if no specific entry will be found, then the pacjet will be routed to the default next hopdefined in the ACL.

asked 16/09/2024
ahmed bin shehab
45 questions

Question 2

Report Export Collapse

Examine the following ACL rule policies:

Permit traffic from 10.2.2.1 through 10.2.2.30 to anywhere

Permit traffic from 10.2.2.40 through 10.2.2.55 to anywhere

Deny all others

Based on this policy, place the following ACL rule statements in the correct order to accomplish the above filtering policy.

deny ip 10.2.2.31 255.255.255.255 anypermit ip 10.2.2.40 255.255.255.248 anypermit ip 10.2.2.48 255.255.255.248 anydeny ip 10.2.2.32 255.255.255.224 anypermit ip 10.2.2.0 255.255.255.192 any
deny ip 10.2.2.31 255.255.255.255 anypermit ip 10.2.2.40 255.255.255.248 anypermit ip 10.2.2.48 255.255.255.248 anydeny ip 10.2.2.32 255.255.255.224 anypermit ip 10.2.2.0 255.255.255.192 any
permit ip 10.2.2.40 255.255.255.248 anypermit ip 10.2.2.48 255.255.255.248 anypermit ip 10.2.2.0 255.255.255.192 anydeny ip 10.2.2.31 255.255.255.255 anydeny ip 10.2.2.32 255.255.255.224 any
permit ip 10.2.2.40 255.255.255.248 anypermit ip 10.2.2.48 255.255.255.248 anypermit ip 10.2.2.0 255.255.255.192 anydeny ip 10.2.2.31 255.255.255.255 anydeny ip 10.2.2.32 255.255.255.224 any
deny ip 10.2.2.31 255.255.255.255 anydeny ip 10.2.2.32 255.255.255.224 anypermit ip 10.2.2.40 255.255.255.248 anypermit ip 10.2.2.48 255.255.255.248 anypermit ip 10.2.2.0 255.255.255.192 any
deny ip 10.2.2.31 255.255.255.255 anydeny ip 10.2.2.32 255.255.255.224 anypermit ip 10.2.2.40 255.255.255.248 anypermit ip 10.2.2.48 255.255.255.248 anypermit ip 10.2.2.0 255.255.255.192 any
deny ip 10.2.2.31 255.255.255.255 anypermit ip 10.2.2.40 255.255.255.248 anydeny ip 10.2.2.32 255.255.255.224 anypermit ip 10.2.2.48 255.255.255.248 anypermit ip 10.2.2.0 255.255.255.192 any
deny ip 10.2.2.31 255.255.255.255 anypermit ip 10.2.2.40 255.255.255.248 anydeny ip 10.2.2.32 255.255.255.224 anypermit ip 10.2.2.48 255.255.255.248 anypermit ip 10.2.2.0 255.255.255.192 any
Suggested answer: A
asked 16/09/2024
Jonathan McGurgan
34 questions

Question 3

Report Export Collapse

What are best practices when implementing VSX on AOS-CX switches? (Choose two.)

The ISL lag should use the default MTU size.
The ISL lag should use the default MTU size.
Timers should be left at their default values.
Timers should be left at their default values.
The default system MAC addresses should be used.
The default system MAC addresses should be used.
The keepalive connection should use a direct layer-3 connection.
The keepalive connection should use a direct layer-3 connection.
The ISL lag should use at least 10GbE links or faster.
The ISL lag should use at least 10GbE links or faster.
Suggested answer: B, D
asked 16/09/2024
shubha sunil
36 questions

Question 4

Report Export Collapse

An administrator wants to implement dynamic segmentation policies. The network consists of AOSCX and Aruba gateways.

Which type of forwarding should the administrator implement for users that already connect via wireless, but will also be connecting on Ethernet switch ports?

User-based tunneling (UBT)
User-based tunneling (UBT)
Port-based tunneling (PBT)
Port-based tunneling (PBT)
Switch-to-switch tunneling (SST)
Switch-to-switch tunneling (SST)
Local switching
Local switching
Suggested answer: A
asked 16/09/2024
Feras Al Babtain
27 questions

Question 5

Report Export Collapse

Examine the partial output of the BGP routing table of an AOS-CX switch:

HP HPE6-A73 image Question 5 14574 09162024180711000000

The switch is learning about four possible path to reach the 1.0.0.0/8 network. Based on this output, which next-hop route will the AOS-CX select to be placed in the IP routing table?

192 168 1 5
192 168 1 5
192 168 2 5
192 168 2 5
192 168 3 5
192 168 3 5
192 1684 5
192 1684 5
Suggested answer: C
asked 16/09/2024
Charles Brono
45 questions

Question 6

Report Export Collapse

What is correct regarding rate limiting and egress queue shaping on AOS-CX switches?

Rate limiting and egress queue shaping can be used to restrict inbound traffic
Rate limiting and egress queue shaping can be used to restrict inbound traffic
Limits can be defined only for broadcast and multicast traffic
Limits can be defined only for broadcast and multicast traffic
Rate limiting and egress queue shaping can be applied globally
Rate limiting and egress queue shaping can be applied globally
Traffic rate limit is configured on queue level
Traffic rate limit is configured on queue level
Suggested answer: D
asked 16/09/2024
Gurdeep Girn
31 questions

Question 7

Report Export Collapse

What is the correct way of associating a VRF instance to either a VLAN or an interface?

Switch(config)# interface <interface-ID>Switch(config-if)# vlan access <VLAN-ID> vrf attach <vrf-name>
Switch(config)# interface <interface-ID>Switch(config-if)# vlan access <VLAN-ID> vrf attach <vrf-name>
Switch(config)# vlan <VLAN-ID> vrf attach < vrf-name >
Switch(config)# vlan <VLAN-ID> vrf attach < vrf-name >
Switch(config)# vlan <VLAN-ID>Switch(config-vlan-<VLAN-ID># vrf attach < vrf-name >
Switch(config)# vlan <VLAN-ID>Switch(config-vlan-<VLAN-ID># vrf attach < vrf-name >
Switch(config)# vlan <VLAN-ID> vrf < vrf-name >
Switch(config)# vlan <VLAN-ID> vrf < vrf-name >
Suggested answer: C
asked 16/09/2024
cristian vargas
42 questions

Question 8

Report Export Collapse

A company has a third-party AAA server solution. The campus access layer was just upgraded to AOSCX switches that perform access control with MAC-Auth and 802.1X. The company has an Aruba Mobility Controller (MC) solution for wireless, and they want to leverage the firewall policies on the controllers for the wired traffic.

What is correct about how the company should implement a security solution where the wired traffic is processed by the MCs?D18912E1457D5D1DDCBD40AB3BF70D5D

Implement downloadable user roles with a gateway role defined on the AOS-CX switches
Implement downloadable user roles with a gateway role defined on the AOS-CX switches
Implement local user roles with a gateway role defined on the AOS-CX switches
Implement local user roles with a gateway role defined on the AOS-CX switches
Implement standards-based RADIUS VSAs to pass policy information directly to the AOS-CX switches and MCs
Implement standards-based RADIUS VSAs to pass policy information directly to the AOS-CX switches and MCs
Implement downloadable user roles with a device role defined on the AOS-CX switches and MCs
Implement downloadable user roles with a device role defined on the AOS-CX switches and MCs
Suggested answer: B
asked 16/09/2024
Ange YAO
38 questions

Question 9

Report Export Collapse

An administrator wants to leverage always-on PoE on AOS-CX switches. Which statement is correct regarding this feature?

Provides up to 60W of power per port
Provides up to 60W of power per port
Supports all AOS-CX switches
Supports all AOS-CX switches
Provides surge protection for PoE and non-PoE ports
Provides surge protection for PoE and non-PoE ports
Requires NetEdit to implement
Requires NetEdit to implement
Suggested answer: A
asked 16/09/2024
ozgur yilmaz
30 questions

Question 10

Report Export Collapse

A network administrator is attempting to troubleshoot a connectivity issue between a group of users and a particular server. The administrator needs to examine the packets over a period of time from their desktop; however, the administrator is not directly connected to the AOS-CX switch involved with the traffic flow.

What is correct regarding the ERSPAN session that needs to be established on an AOS-CX switch?

(Choose two.)

On the source AOS-CX switch, the destination specified is the switch to which the administrator's desktop is connected
On the source AOS-CX switch, the destination specified is the switch to which the administrator's desktop is connected
On the source AOS-CX switch, the destination specified is the administrator's desktop
On the source AOS-CX switch, the destination specified is the administrator's desktop
The encapsulation protocol used is GRE
The encapsulation protocol used is GRE
The encapsulation protocol used is VXLAN
The encapsulation protocol used is VXLAN
The encapsulation protocol is UDP
The encapsulation protocol is UDP
Suggested answer: A, C
Explanation:

In AOS CX the remote mirroring is done using a tunnel interface, so the Mirror source and destination must be configured on each Switch. On the source Switch, the source interface (from where the traffic is mirrored) and destination interface (the tunnel interface to where the traffic is sent to). In the destination Switch, the source interface (which would be the tunnel interface (receiving the traffic from the source switch tunnel)) and the destination would be the client where Wireshark enabled client is connected.

asked 16/09/2024
Gurdeep Girn
31 questions
Total 127 questions
