CompTIA N10-008 Practice Test - Questions Answers, Page 51

A fiber distribution panel is a device that provides a central location for connecting and managing fiber optic cables and optical modules. It can support various types and speeds of fiber optic links,

including multimode uplinks. Therefore, a fiber distribution panel should be used to manage outside cables that need to be routed to various multimode uplinks.

Port security is a feature that allows a network device to limit the number and type of MAC addresses that can access a port. Port security can prevent unauthorized devices from connecting to the network through an available network jack. Therefore, port security is the most likely cause of the connectivity issues for some mobile users in the new lobby.

The default gateway is the IP address of the router that connects the PC to other networks. The default gateway should be on the same subnet as the PC’s IPv4 address. However, in this case, the default gateway is 192.168.9.1, which is on a different subnet than the PC’s IPv4 address of 192.168.8.15. Therefore, the default gateway configuration on the PC is incorrect and prevents the PC from reaching the file server on another subnet.

MAC filtering is a method of allowing only company-owned devices to associate with the network by using their MAC addresses as identifiers. A MAC address is a unique identifier assigned to each network interface card (NIC) by the manufacturer. MAC filtering can be configured on the wireless access point to allow or deny access based on the MAC address of the device. This way, only devices with known MAC addresses can connect to the network. Reference:

https://www.comptia.org/training/books/network-n10-008-study-guide (page 323)

A memorandum of understanding (MOU) is a document that describes an agreement between two or more parties on how to utilize shared resources for a project. An MOU is not legally binding, but it outlines the expectations and responsibilities of each party involved in the collaboration. An MOU can be used when two international companies want to share cloud resources for a project without creating a formal contract. Reference: https://www.comptia.org/training/books/network-n10-008study-guide

(page 405)

A 110 block is a type of punch-down block that is used to distribute Ethernet to multiple computers in an office. A punch-down block is a device that connects one group of wires to another group of wires by using a special tool that pushes the wires into slots on the block. A 110 block is a nonproprietary standard that supports up to Category 6 cabling and can be used for voice or data applications. Reference: https://www.comptia.org/training/books/network-n10-008-study-guide

(page 64)

Firmware is the software that runs on network equipment such as routers, switches, and VPN appliances. Firmware updates often contain bug fixes, security patches, and performance improvements that can prevent or mitigate vulnerabilities and attacks. By routinely upgrading all network equipment firmware, a network administrator can ensure that the network devices are running the latest and most secure versions of firmware and avoid exploiting known and fixed remote code execution vulnerabilities in the VPN appliance. Reference:

https://www.comptia.org/training/books/network-n10-008-study-guide (page 462)

A helper address is an IP address that is configured on a router interface to forward DHCP broadcast messages to a DHCP server on another LAN. A DHCP broadcast message is a message that a workstation sends when it needs to obtain an IP address from a DHCP server. Since broadcast messages are not routed across different networks, a helper address is needed to relay the DHCP broadcast message to the DHCP server on another network. Reference:

https://www.comptia.org/training/books/network-n10-008-study-guide (page 199)

Port mirroring is a feature that allows a network technician to monitor traffic on a specific port on a switch by copying all the traffic from that port to another port where a monitoring device is connected. Port mirroring can be used for troubleshooting, analysis, or security purposes, such as detecting network anomalies, performance issues, or malicious activities. Reference:

https://www.comptia.org/training/books/network-n10-008-study-guide (page 156)
