F5 201 Practice Test - Questions Answers, Page 4

Add to Whishlist

List of questions

Question 31

Report Export Collapse

A BIG-IP Administrator makes a configuration change to a Virtual Server on the Standby device of an HA pair. The HA pair is currently configured with Auto-Sync Enabled. What effect will the change have on the HA pair configuration?

The change will be undone when Auto-Sync propagates the config to the HA pair.
The change will be undone when Auto-Sync propagates the config to the HA pair.
The change will be propagated next time a configuration change is made on the Active device.
The change will be propagated next time a configuration change is made on the Active device.
The change will be undone next time a configuration change is made on the Active device.
The change will be undone next time a configuration change is made on the Active device.
The change will take effect when Auto-Sync propagates the config to the HA pair.
The change will take effect when Auto-Sync propagates the config to the HA pair.
Suggested answer: D
asked 24/09/2024
Chakravarthy Sankaranarayanan
38 questions

Question 32

Report Export Collapse

A user wants to use the iHealth Upgrade Advisor to determine any issues with upgrading TMOS from 13.0 to 13.1.

Where can the user generate the QKView to upload to iHealth?

System > Software Management
System > Software Management
System > Archives
System > Archives
System > Configuration
System > Configuration
System > Support
System > Support
Suggested answer: D
asked 24/09/2024
Ronald DeCastro
37 questions

Question 33

Report Export Collapse

A BIG-IP Administrator is receiving intermittent reports from users that SSL connections to the BIG-IP device are failing. Upon checking the log files, the BIG-IP Administrator notices the following error message:

ere tmm<instance>[]: 01260008:3: SSL transaction (TPS) rate limit reached

After reviewing statistics, the BIG-IP Administrator notices there are a maximum of 1200 client-side SSL

TPS and a maximum of 800 server-side SSL TPS.

What is the minimum SSL license limit capacity the BIG-IP Administrator should upgrade to handle this peak?

2000
2000
400
400
800
800
1200
1200
Suggested answer: D
asked 24/09/2024
Jonathan McGurgan
40 questions

Question 34

Report Export Collapse

Users report that traffic is negatively affected every time a BIG-IP device fails over. The traffic becomes stabilized after a few minutes.

What should the BIG-IP Administrator do to reduce the impact of future failovers?

Enable Failover Multicast Configuration
Enable Failover Multicast Configuration
Set up Failover Method to HA Order
Set up Failover Method to HA Order
Configure MAC Masquerade
Configure MAC Masquerade
Configure a global SNAT Listener
Configure a global SNAT Listener
Suggested answer: C
asked 24/09/2024
Bill Skadden
39 questions

Question 35

Report Export Collapse

A BIG-IP Administrator plans to resolve a non-critical issue with a BIG-IP device in 2 weeks. What Severity level should be assigned to this type of F5 support ticket?

4
4
2
2
3
3
1
1
Suggested answer: A
asked 24/09/2024
Katherine Messick
43 questions

Question 36

Report Export Collapse

A BIG-IP Administrator adds new Pool Members into an existing, highly utilized pool. Soon after, there are reports that the application is failing to load for some users. What pool level setting should the BIG-IP Administrator check?

Availability Requirement
Availability Requirement
Allow SNAT
Allow SNAT
Action On Service Down
Action On Service Down
Slow Ramp Time
Slow Ramp Time
Suggested answer: D
Explanation:

Option ABC is a global configuration, has nothing to do with the new pool member, select D after excluding

asked 24/09/2024
LEONARDO CESAR MARQUES
52 questions

Question 37

Report Export Collapse

Administrative user accounts have been defined on the remote LDAP server and are unable to log in to the BIG-IP device.

Which log file should the BIG-IP Administrator check to find the related messages?

/var/log/secure
/var/log/secure
/var/log/messages
/var/log/messages
/Nar/log/ltm
/Nar/log/ltm
/var/log/user.log
/var/log/user.log
Suggested answer: A
asked 24/09/2024
lakshmi govindu
48 questions

Question 38

Report Export Collapse

Refer to the exhibit.

F5 201 image Question 38 82949 09242024194133000000

A BIG-IP Administrator creates a new Virtual Server. The end user is unable to access the page. During troubleshooting, the administrator learns that the connection between the BIG-IP system and server is

NOT set up correctly.

What should the administrator do to solve this issue?

Disable Address Translation
Disable Address Translation
Set Address Translation to Auto Map, configure a SNAT pool, and have pool members in the same subnet of the servers
Set Address Translation to Auto Map, configure a SNAT pool, and have pool members in the same subnet of the servers
Set Address Translation to SNAT and configure a specific translation address
Set Address Translation to SNAT and configure a specific translation address
Set Address Translation to SNAT and have self-IP configured in the same subnet of servers
Set Address Translation to SNAT and have self-IP configured in the same subnet of servers
Suggested answer: C
Explanation:

The status of the pool can be seen that the members are all up, indicating that the network from F5 to the server is no problem, so there is no need to configure selfip on the same subnet. The monitor is normal but the access is not normal, you have to consider the problem of snat, you can configure automap or configure snat and specify snat ip.

asked 24/09/2024
Gerhard Seher
32 questions

Question 39

Report Export Collapse

Which type of Virtual Server requires the use of a FastL4 profile?

Performance (Layer 4)
Performance (Layer 4)
Stateless
Stateless
Performance (HTTP)
Performance (HTTP)
Standard
Standard
Suggested answer: A
asked 24/09/2024
Bogdan Karolic
52 questions

Question 40

Report Export Collapse

A BIG-IP Administrator plans to upgrade a BIG-IP device to the latest TMOS version.

Which two tools could the administrator leverage to verify known issues for the target versions?

(Choose two.)

F5 University
F5 University
F5 Downloads
F5 Downloads
F5 End User Diagnostics (EUD)
F5 End User Diagnostics (EUD)
FSiHealth
FSiHealth
F5 Bug Tracker
F5 Bug Tracker
Suggested answer: D, E
Explanation:

F5 University -- F5 learning materials

F5 Downloads - iso download page

F5 End User Diagnostics (EUD) -- Hardware detection

asked 24/09/2024
nebaba monda
57 questions
Total 254 questions
