An LTM Specialist needs to create a virtual server to pass TCP traffic to three pool members.
Which two virtual server types should be used to meet the requirements? (Choose two)
An LTM Specialist needs to add a pool that will load balance MYSOL services. It has four members, each with differing hardware platforms. All pool members are already assigned to another pool for load balancing FTP traffic.
Which load balancing method is most effective when the LTM Specialist sets up the pool?
While working with a web developer, it is determined that additional logic is required to assess the pool member availability.
Which two monitor types should be used in this scenario? (Choose two)
An LTM device configured with a management IP address and route and a series of self-IPs and TMM routes. Both management and TMM have a routing entry for 101 10/24 Application traffic is being load balanced and sent to pool member 10.1.1.123 with SNAT Automap and configured.
Which route will the LTM device use?
An application is sensitive to packet loss and unexpected session termination. A pair of LTM devices is configured in an Active/Standby high availability configuration. SNATS are NOT used and the virtual server contains a Universal Persistence profile.
which two actions must an LTM Specialist take to ensure the sessions are maintained between the client and server during an LTM device failover event while maintaining maximum uptime? (Choose two.)
A web server's default gateway is the network router. The LTM Specialist needs to introduce an LTM device to load balance to the web servers without changing the server's default gateway.
Which deployment method and settings should the LTM Specialist use to ensure correct traffic flow and that the web servers can obtain the actual con IP addresses?
Exhibit.
The LTM devices LTM1 and LTM2 are configured in a Device Group (Sync Failover) with Network Failover configured on both the management and HA and Internal VLANS. and ConfigSync is confined in a Device Group (Sync Failover) with Network Failover and internal are tagged on a single trunk with subnets Connection Mirroring is configured on both the HA interlace directly connected between LTM1 and LTM2, and the management interlace is connected to a management switch. The LTM devices have four Traffic Groups defined, and both LTM devices are healthy and capable of passing traffic for any of the Traffic Groups.
An LTM Specialist disconnects the cable for the HA network in an effort to test failover.
Which HA functionality works in this case?
Refer to the exhibit.
An LTM Specialist configures the two syslog destination Syslog destination #1 can receive messages but the syslog destination #2 can NOT receive messages.
Which command sill correct the issue?
An LTM Specialist needs to enable TCP connection re-use for a non-HTTP application. The application uses a simple request response protocol where each request and response is contained within a single packet.
Which configuration option should the LTM Specialist adjust?
An HA pair of LTM devices that load balance multiple HTTPS applications utilizes highly customized RAM Cache and compression profiles on each virtual server. The LTM Specialist who is administering the HA pair regularly observes entines in the log similar to the following:
tmm tmm I708S1 011e0002.4. sweeper_update: aggressive mode activated (117504/138240 pages)
No DoS attacks arc occurring. No user problems have been reported. Which step should the LTM Specialist take to help mitigate the issue?
