Cisco 350-801 Practice Test - Questions Answers, Page 43

These are two parameters that influence the total number of supported conference participants on a Cisco IOS XE router that has DSP modules2. A voice codec is a software algorithm that compresses and decompresses voice signals for transmission over a network3. Different voice codecs have

different bandwidth requirements and quality levels3. A PVDM module is a hardware component that provides digital signal processing (DSP) resources for voice applications such as conferencing and transcoding1. A PVDM module has a fixed session capacity, which is the maximum number of voice channels that it can support simultaneously1.

The dtmf-relay command is used to configure DTMF relay on a Cisco Unified Border Element. The rtpnte option specifies that RFC2833 is the preferred relay mechanism, and the sip-kpml option specifies that KPML is the next preferred relay mechanism.

The Cisco Directory Connector is a software application that is installed on a dedicated on-premises server. It synchronizes user identities between the on-premises directory and the Cisco Webex cloud.

1. 100 Trying

2. 180 Ringing

3. two-way voice path

4. Connect ACK

5. two-way RTP channel

Diagnostic signatures are a feature that proactively detects commonly observed issues in the IOS XEbased Local Gateway and generates email, syslog, or terminal message notification of the event12. You can also install the diagnostic signatures to automate diagnostics data collection and transfer collected data to the Cisco TAC case to accelerate resolution time12.

Call forwarding is a feature that allows users to forward incoming calls to another number. This can be useful in a number of situations, such as when a user is not available to take a call, or when a user wants to forward calls to a different number during certain times of the day.

Call forwarding can be used to improve business continuity by ensuring that calls are always answered, even if the user is not available. For example, if a user is out of the office, they can forward their calls to their voicemail or to another employee. This ensures that customers and clients

can always reach someone, even if the user is not available.

The ALLUSERS property is a command-line argument that can be used to install the Webex app as a "per machine" installation. This means that the app will be installed for all users on the computer, regardless of which user account is currently logged in.

The ACCEPT_EULA property is a command-line argument that can be used to accept the end-user license agreement (EULA) for the Webex app. The INSTALL_ROOT property is a command-line argument that can be used to specify the installation directory for the Webex app. The FORCELOCKDOWN property is a command-line argument that can be used to prevent users from uninstalling the Webex app.

This is a prerequisite for using the Device Connector tool, which allows you to onboard and register several devices simultaneously to the Webex Control Hub1. The Device Connector tool creates a workspace, an activation code, and activates all of your devices in one go1. This way you don’t need to be physically present in the same room to activate the devices.

The other options are not required before onboarding devices by using the Control Hub:

Configuring the Control Hub organization ID on the devices is not necessary, as the Device Connector tool will send the device information to your Webex organization and generate activation codes for them1.

Acquiring a license for each device is not necessary, as you can assign licenses to users and devices after they are registered to the Webex Control Hub2.

Allowing HTTP traffic from each device to Control Hub is not necessary, as HTTPS connectivity is required for the Device Connector tool to communicate with the devices1.

TFTP is a network protocol that is used to transfer files between devices. It is often used to transfer firmware and configuration files to network devices. In order to use TFTP, the device must have a TFTP server configured.

In Cisco UCM, the TFTP server is configured on the serviceability page. The TFTP server can be configured on any node that has Cisco UCM service enabled. The TFTP server cannot be configured on nodes that do not have Cisco UCM service enabled.
