After integrating Cisco Unity Express with Cisco Unified Communications Manager Express, users report that the system does not respond to their digit presses. Which two configuration snippets resolve this issue? (Choose two.)
dial-peer voice 6800 voip
destination-pattern 5...
session protocol sipv2
session target ipv4:10.3.6.127
dtmf-relay sip-kpml
codec g729r8
dial-peer voice 6800 voip
destination-pattern 5...
session protocol sipv2
session target ipv4:10.3.6.127
dtmf-relay sip-notify
codec g711ulaw
dial-peer voice 6800 voip
destination-pattern 5...
session protocol sipv2
session target ipv4:10.3.6.127
dtmf-relay rtp-nte
codec g711ulaw
dial-peer voice 6800 voip
destination-pattern 5...
session protocol sipv2
session target ipv4:10.3.6.127
dtmf-relay sip-kpml
codec g711ulaw
dial-peer voice 6800 voip
destination-pattern 5...
session protocol sipv2
session target ipv4:10.3.6.127
dtmf-relay sip-notify
codec g729r8
What prevents toll fraud on voicemail ports?
IP address trusted list on the PSTN gateway
CSS
Block OffNet to OffNet Transfer service parameter
FAC
Which statement describes a role of AXL communications in the BLF Plug-in Service of the Cisco Unified Attendant Console?
The AXL communications allow registered attendants to log in to Cisco Unified Communications Manager and receive calls.
The AXL communications enable Device Resolution Manager to resolve the device statuses of operator and system devices.
The AXL communications is required after installation to verify that the specified CTI manager or managers and Cisco Unified Attendant Console versions match.
The AXL communications is required after installation to verify that the specified CTI manager or managers and Cisco Unified CM versions.
Which type of SRV record provides the location of Cisco Expressway-E?
_collab-edge._tls.example.com
_cisco-uds._tcp.example.com
_cuplogin._tcp.example.com
_http._tcp.example.com
Refer to the exhibit.
Troubleshooting an internal Jabber login issue and you see this logging snippet from the Jabber PRT file. You already checked that the Jabber client has a connection to the correct DNS server. Which DNS record is missing for service discovery of Cisco Unified Communications Manager for the login process to proceed further?
A record for the Cisco Unified Communications Manager
SRV record _cisco-uds._tcp.example.com
A record _cuplogin._tcp.example.com
SRV record _cuplogin._tcp.example.com
Which two SSO features are true? (Choose two.)
allows Jabber to use LDAP directory services for contact imports
allows LDAP user import on Cisco Unified Communications Manager
improves productivity by reducing time spent re-entering credentials for the same identity
transfers the authentication from the system that hosts the applications to a third-party system
reduces costs by decreasing the number of help calls that are made for voicemail PIN resets
Refer to the exhibit.
Calls that are not answered by the user are for the location. If the user at extension 11112222 does not have a voice mailbox, which rule is utilized when Cisco Unity Communication receives the forwarded call?
NewYork_AA
Attempt Sign In
Arizona_AA
Opening_Greeting
Which DNS record is used for on-premises service by Jabber clients?
_collab-edge._tcp.<domain> SRV record
_cisco-uds._tls.<domain> SRV record
_cisco-uds._tcp.<domain> SRV record
<tftp server FQDN> A record
Fraudulent calls are being made from Cisco Unity Connection. Which action prevents the calls from reaching the PSTN using SCCP integration?
Change the configuration of the routing rule.
Change the CSS of the voicemail port.
Change the Rerouting CSS on the trunk to Cisco Unity Connection.
Remove values from restriction table.
An engineer is configuring SAML SSO for a Cisco Unified Communications Manager. After completing all required steps, the engineer wants to verify the status. Which CLI command provides the status of SAML SSO?
utils sso status
show sso status
show saml status
utils saml status
