Cisco 350-401 Practice Test - Questions Answers, Page 37

Fabric Enabled WLC:

Fabric enabled WLC is integrated with LISP control plane. This WLC is responsible for AP image /Config, Radio Resource Management, Client Session management and roaming and all other wireless control plane functions.

For WLC Fabric Integration:

Wireless Client MAC address is used as EID

It inform about Wireless MAC address with its other information like SGT and Virtual Network Information VN information is mapped to VLAN on FEs WLC is responsible for updating Host Database tracking DB with roaming information

A TLOC is a Transport Locator that represents an attachment point where a Cisco WAN Edge device connects to a WAN transport. A TLOC is uniquely identified by a tuple of three values - (System-IP address, Color, Encapsulation).

A TLOC route consists of all required information needed by a remote peer in order to establish an overlay tunnel with that TLOC. This includes private and public IP addresses and ports, site-id, preference, weight, status, encapsulation info such as encryption and authentication parameters, and much more.

Cisco DNA Center creates the backup files and posts them to a remote server. Each backup is uniquely stored using the UUID as the directory name.To support Assurance data backups, the server must be a Linux-based NFS server that meets the following requirements:

– Support NFS v4 and NFS v3.

– Cisco DNA Center stores backup copies of Assurance data on an external NFS device and automation data on an external remote sync (rsync) target location.

– The remote share for backing up an Assurance database (NDP) must be an NFS share.

Reference: https://www.cisco.com/c/en/us/td/docs/cloud-systems-management/networkautomation-and-management/dna-center/2-1-2/admin_guide/b_cisco_dna_center_admin_guide_2_1_2/

b_cisco_dna_center_admin_guide_2_1_1_chapter_0110.html
