Cisco 350-401 Practice Test - Questions Answers, Page 85

This is because a top-to-bottom approach is a troubleshooting methodology that starts from the highest layer of the OSI model and works its way down to the lowest layer. The technician is using this approach by first testing the network layer connectivity with the ping command, which uses the ICMP protocol. If the ping is successful, the technician can move on to the next layer, such as the transport layer or the application layer. If the ping fails, the technician can troubleshoot the lower layers, such as the data link layer or the physical layer. The source of this answer is the Cisco ENCOR v1.1 course, module 10, lesson 10.3: Applying Troubleshooting Methodologies.

This is because EIGRP is an advanced distance vector routing protocol that uses a composite metric to calculate the best path to a destination. EIGRP has a default administrative distance value of 90, which means that it is more trustworthy than RIP (120) or OSPF (110), but less trustworthy than BGP (20). The source of this answer is the Cisco ENCOR v1.1 course, module 4, lesson 4.1: Implementing EIGRP.

This is because a palm scanner is a type of biometric security method that uses the physical characteristics of a person's palm, such as the shape, size, and vein patterns, to authorize access to a location. A palm scanner is more reliable and secure than other methods, such as a PIN pad or a digital card reader, which can be easily stolen, lost, or shared. A palm scanner is also more hygienic and convenient than other biometric methods, such as a fingerprint scanner or a facial recognition system, which can be affected by dirt, oil, or lighting conditions. The source of this answer is the Cisco ENCOR v1.1 course, module 2, lesson 2.2: Implementing Device Access Control.

This is because a dictionary attack is a type of password cracking attack that uses a list of common or previously leaked passwords to guess the credentials of a user. A dictionary attack becomes more effective because of global leakages of users' passwords, as the attacker can use the leaked passwords as a source for the dictionary. The source of this answer is the Cisco ENCOR v1.1 course, module 2, lesson 2.3: Implementing Wireless Security.

This is because NAC stands for network access control, which is a security mechanism that allows or denies access to a network based on the identity and compliance of the device. NAC can prevent unauthorized visitors from accessing the corporate network by plugging personal laptops into open network ports, as NAC can enforce policies such as authentication, authorization, posture assessment, and remediation. The source of this answer is the Cisco ENCOR v1.1 course, module 2, lesson 2.4: Implementing Network Access Control.

The workstation was configured with a static IP that is the same as the server. This is because if two devices on the same network have the same IP address, they will cause an IP address conflict, which will prevent them from communicating with other devices on the network. The users who were moved to different desks may have been assigned static IP addresses that were not updated after the move, and they may have accidentally used the same IP address as the server. The source of this answer is the Cisco ENCOR v1.1 course, module 3, lesson 3.1: Implementing IPv4 and IPv6 Addressing.

This is because ports can become error disabled when they detect certain errors or violations on the network, such as a loop, a security breach, or a duplex mismatch. When a port is error disabled, it shuts down and stops forwarding traffic until it is manually re-enabled by the administrator. The users who were moved to different desks may have plugged their devices into ports that were configured with different settings or security policies than their original ports, and this may have triggered the error disable state. The source of this answer is the Cisco ENCOR v1.1 course, module 3, lesson 3.3: Implementing EtherChannel.

Option B is the correct command set to update the existing configuration to achieve the desired results.The configuration steps are as follows12:

Define a standard access list that permits only the administrators from the 192.168.1.0/24 subnet to access the vty lines. In this case, the access list is namedADMINand it allows any host with an IP address in the range of 192.168.1.1 to 192.168.1.254 to access the vty lines:ip access-list standard ADMINandpermit 192.168.1.0 0.0.0.255.

Apply the access list to the vty lines using theaccess-classcommand. This command restricts incoming and outgoing connections between a particular vty and the addresses in the access list. In this case, the access listADMINis applied to the vty lines 0 to 15 in the inbound direction, which means that only the hosts that match the access list can initiate a connection to the vty lines:line vty 0 15andaccess-class ADMIN in.

Disable the clear-text protocols such as Telnet for the vty lines using thetransport inputcommand. This command specifies which protocols are allowed for incoming connections. In this case, only SSH is allowed for the vty lines, which is a secure protocol that encrypts the data between the client and the server:transport input ssh.

Option A is incorrect because it does not apply the access list to the vty lines, which is required to restrict the access to the administrators from the 192.168.1.0/24 subnet.Without theaccess-classcommand, any host can attempt to connect to the vty lines12.

Option C is incorrect because it does not disable the clear-text protocols for the vty lines, which is required to prohibit the access to the vty lines using unsecure protocols.Without thetransport input sshcommand, both Telnet and SSH are allowed for the vty lines by default12.

Option D is incorrect because it uses an extended access list instead of a standard access list, which is not recommended for controlling access to the vty lines. An extended access list requires more configuration and processing than a standard access list, and it cannot be applied directly to the vty lines.It has to be applied to each interface that can be used to access the vty lines, which increases the complexity and the possibility of errors12.Reference:1:Controlling Access to a Virtual Terminal Line,2:Configuring Secure Shell
