Refer to the exhibit. What are two conclusions about this configuration? {Choose two.)

The spanning-tree mode is Rapid PVST+.

The root port is FastEthernet 2/1.

The designated port is FastEthernet 2/1.

The spanning-tree mode is PVST+.

What is a function performed by a web server?

provide an application that is transmitted over HTTP

send and retrieve email from client devices

authenticate and authorize a user's identity

securely store flies for FTP access

Which command entered on a switch configured with Rapid PVST* listens and learns for a specific time period?

switch(config)#spanning-tree vlan 1 forward-time 20

switch(config)#spanning-tree vlan 1 max-age 6

switch(config)#spanning-tree vlan 1 hello-time 10

switch(config)#spanning-tree vlan 1 priority 4096

switch(config)#spanning-tree vlan 1 forward-time 20

Refer to the exhibit. Refer to the exhibit Router R1 Fa0/0 is unable to ping router R3 Fa0'1. Which action must be taken in router R1 to help resolve the configuration issue?

configure a static route with 10.10.10.2 as the next hop to reach the 20.20.20.0/24 network

set the default network as 20.20.20.0/24

set the default gateway as 20.20.20.2

configure a static route with Fa0/1 as the egress interface to reach the 20.20.20.0/24 network

configure a static route with 10.10.10.2 as the next hop to reach the 20.20.20.0/24 network

What is the difference between 1000BASE-LX/LH and 1000BASE-ZX interfaces?

1000BASE-LX/LH is supported on links up to 10km, and 1000BASE-ZX operates over links up to 70 km

1000BASE-ZX is supported on links up to 1000km, and 1000BASE-LX/LH operates over links up to 70 km.

1000BASE-LX/LH interoperates with multimode and single-mode fiber, and 10008ASE-ZX needs a conditioning patch cable with a multimode.

1000BASE-LX/LH is supported on links up to 10km, and 1000BASE-ZX operates over links up to 70 km

1000BASE-ZX interoperates with dual-rate 100M/1G 10Km SFP over multimode fiber, and 1000BASE-LX/LH supports only single-rate.

What is a benefit for external users who consume public cloud resources?

implemented over a dedicated WAN

located in the same data center as the users

How does authentication differ from authorization?

Authentication verifies the identity of a person accessing a network, and authorization determines what resource a user can access.

Authentication is used to record what resource a user accesses, and authorization is used to determine what resources a user can access

Authentication is used to determine what resources a user is allowed to access, and authorization is used to track what equipment is allowed access to the network

Authentication is used to verify a person's identity, and authorization is used to create syslog messages for logins.

When should an engineer implement a collapsed-core architecture?

for large networks that are connected to multiple remote sites

for small networks with minimal need for growth

the access and distribution layers must be on the same device

for large networks that are connected to multiple remote sites

What is the default port-security behavior on a trunk link?

It causes a network loop when a violation occurs.

It disables the native VLAN configuration as soon as port security is enabled.

It places the port in the err-disabled state if it learns more than one MAC address.

It places the port in the err-disabled slate after 10 MAC addresses are statically configured.

When a switch receives a frame for an unknown destination MAC address, how is the frame handled?

inspected and dropped by the switch

broadcast to all ports on the switch

flooded to all ports except the origination port

forwarded to the first available port

inspected and dropped by the switch

Refer to the exhibit. An engineer is configuring a Layer 3 port-channel interface with LACP. The configuration on the first device is complete, and it is verified that both interfaces have registered the neighbor device in the CDP table. Which task on the neighbor device enables the new port channel to come up without negotiating the channel?

Modify the static EtherChannel configuration of the device to passive mode.

Change the EtherChannel mode on the neighboring interfaces to auto.

Configure the IP address of the neighboring device.

Bring up the neighboring interfaces using the no shutdown command.

Modify the static EtherChannel configuration of the device to passive mode.

What is the purpose of the Cisco DNA Center controller?

to securely manage and deploy network devices

to secure physical access to a data center

to scan a network and generate a Layer 2 network diagram

to securely manage and deploy network devices

to provide Layer 3 services to autonomous access points

Refer to the exhibit. After configuring a new static route on the CPE. the engineer entered this series of commands to verify that the new configuration is operating normally When is the static default route installed into the routing table?

when 203 0 113.1 is no longer reachable as a next hop

when the default route learned over external BGP becomes invalid

when a route to 203.0 113 1 is learned via BGP

when the default route over external BGP changes its next hop

How does encryption project the wireless network?

via an algorithm to change wireless data so that only the access point and client understand it

via integrity checks to identify wireless forgery attacks in the frame

via specific ciphers to detect and prevent zero-day network attacks

via an algorithm to change wireless data so that only the access point and client understand it

via a policy to prevent unauthorized users from communicating on the wireless network

Which action implements physical access control as part of the security program of an organization1?

configuring a password for the console port

backing up syslogs at a remote location

configuring a password for the console port

configuring enable passwords on network devices

setting up IP cameras to monitor key infrastructure

to provide end users with a virtual gateway in a multivendor network

to leverage a weighting scheme to provide uninterrupted service

to detect link failures without the overhead of Bidirectional Forwarding Detection

to hand over to end users the autodiscovery of virtual gateways

A packet from a company s branch office is destined to host 172.31.0.1 at headquarters. The sending router has three possible matches in its routing table for the packet prefixes: 172. 31.0 .0/16.72.31.0.0724. and 172.31 0 0/25. How does the router handle the packet?

It sends the traffic via prefix 172.31.0.0/25

It sends the traffic via prefix 172.31.0.0/16

It sends the traffic via the default gateway 0.0.0.070.

It sends the traffic via prefix 172.31.0.0/24

It sends the traffic via prefix 172.31.0.0/25
