After installing a new Cisco ISE server, which task must the engineer perform on the Cisco WLC to connect wireless clients on a specific VLAN based on their credentials?
Enable the allow AAA Override
Enable the Even: Driven RRM.
Disable the LAG Mode or Next Reboot.
Enable the Authorized MIC APs against auth-list or AAA.
A network analyst is tasked with configured the date and time on a router using EXEC mode. The date must be set to 12:00am. Which command should be used?
Clock timezone
Clock summer-time-recurring
Clock summer-time date
Clock set
A network administrator is asked to configure VLANS 2, 3 and 4 for a new implementation. Some ports must be assigned to the new VLANS with unused remaining. Which action should be taken for the unused ports?
configure port in the native VLAN
configure ports in a black hole VLAN
configure in a nondefault native VLAN
configure ports as access ports
Refer to the exhibit.
Router R4 is dynamically learning the path to the server. If R4 is connected to R1 via OSPF Area 20, to R2 v2ia R2 BGP, and to R3 via EIGRP 777, which path is installed in the routing table of R4?
the path through R1, because the OSPF administrative distance is 110
the path through R2. because the IBGP administrative distance is 200
the path through R2 because the EBGP administrative distance is 20
the path through R3. because the EIGRP administrative distance is lower than OSPF and BGP
Why was the RFC 1918 address space defined?
conserve public IPv4 addressing
preserve public IPv6 address space
reduce instances of overlapping IP addresses
support the NAT protocol
Which HTTP status code is returned after a successful REST API request?
200
301
404
500
Refer to the exhibit.
R5 is the current DR on the network, and R4 is the BDR. Their interfaces are flapping, so a network engineer wants the OSPF network to elect a different DR and BDR. Which set of configurations must the engineer implement?
What are network endpoints?
act as routers to connect a user to the service prowler network
a threat to the network if they are compromised
support inter-VLAN connectivity
enforce policies for campus-wide traffic going to the internet
Which two components are needed to create an Ansible script that configures a VLAN on a switch?
(Choose two.)
cookbook
task
playbook
model
recipe
Which two events occur automatically when a device Is added to Cisco DNA Center? (Choose two. )
The device Is assigned to the Global site.
The device Is placed into the Unmanaged state.
The device Is placed into the Provisioned state.
The device Is placed into the Managed state.
The device is assigned to the Local site.
