What are two disadvantages of a full-mesh topology? (Choose two.)
It needs a high MTU between sites.
It has a high implementation cost.
It must have point-to-point communication.
It requires complex configuration.
It works only with BGP between sites.
Refer to the exhibit.
Routers R1 and R2 are configured with RIP as the dynamic routing protocol. A network engineer must configure R1 with a floating static route to serve as a backup route to network 192.168.23. Which command must the engineer configure on R1?
ip route 192.168.23.0 255.255.255.0 192.168.13.3 100
ip route 192.168.23.0 255.255.255.0 192.168.13.3 121
ip route 192.168.23.0 255.255.255.255 192.168.13.3 121
ip route 192.168.23.0 255.255.255.0 192.168.13.3
Which remote access protocol provides unsecured remote CLI access?
console
Telnet
Bash
SSH
A Cisco engineer notices thai two OSPF neighbors are connected using a crossover Ethernet cable.
The neighbors are taking too long to become fully adjacent. Which command must be issued under the interface configuration on each router to reduce the time required for the adjacency to reach the FULL state?
ip ospf network broadcast
ip ospf dead-interval 40
ip ospf network point-to-point
ip ospf priority 0
How does frame switching function on a switch?
forwards frames to a neighbor port using CDP
modifies frames that contain a known source VLAN
inspects and drops frames from unknown destinations
forwards known destinations to the destination port
Refer to the exhibit.
Which format matches the Modified EUI-64 IPv6 interface address for the network 2001:db8::/64?
2001 :db8::5000:0004:5678:0090/64
2001 :db8:4425:5400:77ft:fe07:/64
2001 :db8::5000:00ff:fe04 0000/64
2001 :db8::5200:00ff:fe04:0000/64
Which WLC interface provides out-of-band management in the Cisco Unified Wireless Network Architecture?
service port
virtual
AP-Manager
dynamic
