Which condition must be met before an NMS handles an SNMP trap from an agent?
The NMS software must be loaded with the MIB associated with the trap.
The NMS must be configured on the same router as the SNMP agent
The NMS must receive a trap and an inform message from the SNMP agent within a configured interval
The NMS must receive the same trap from two different SNMP agents to verify that it is reliable.
Refer to the exhibit.
Router R1 Fa0/0 is unable ping router R3 Fa0/1.
Which action must be taken in router R1 to help resolve the configuration issue?
set the default network as 20.20.20.0/24
set the default gateway as 20.20.20.2
configure a static route with Fa0/1 as the egress interface to reach the 20.20.20.0/24 network
configure a static route with 10.10.10.2 as the next hop to reach the 20.20.20.0/24 network
How does a Cisco Unified Wireless network respond to Wi-Fi channel overlap?
It alternates automatically between 2.4 GHz and 5 GHz on adjacent access points
It allows the administrator to assign channels on a per-device or per-interface basis.
It segregates devices from different manufacturers onto different channels.
It analyzes client load and background noise and dynamically assigns a channel.
When a site-to-site VPN is used, which protocol is responsible for the transport of user data?
IKEv2
IKEv1
IPsec
MD5
An engineer is configuring NAT to translate the source subnet of 10.10.0.0/24 to any of three addresses 192.168.30.1, 192.168.3.2, 192.168.3.3 Which configuration should be used?
Option A
Option B
Option C
Option D
What is the primary function of a Layer 3 device?
to analyze traffic and drop unauthorized traffic from the Internet
to transmit wireless traffic between hosts
to pass traffic between different networks
forward traffic within the same broadcast domain
Router A learns the same route from two different neighbors, one of the neighbor routers is an OSPF neighbor and the other is an EIGRP neighbor. What is the administrative distance of the route that will be installed in the routing table?
20
90
110
115
When the active router in an HSRP group fails, what router assumes the role and forwards packets?
backup
standby
listening
forwarding
Which two protocols must be disabled to increase security for management connections to a Wireless LAN Controller? (Choose two )
Telnet
SSH
HTTP
HTTPS
TFTP
Which action does the router take as rt forwards a packet through the network?
The router replaces the source and desinaoon labels wth the sending router uterface label as a source and the next hop router label as a desbnabon
The router encapsulates the source and destination IP addresses with the sending router P address as the source and the neighbor IP address as the destination
The router replaces the original source and destination MAC addresses with the sending router MAC address as the source and neighbor MAC address as the destination
The router encapsulates the original packet and then includes a tag that identifies the source router MAC address and transmit transparently to the destination
